System And Components
114-8140 PANEL GP-CONTROLType 1
Group No: 114-8140
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1145628 | 1 BOX AS | 1 | |
| 5P5906 | SEAL (0.8-M) | ||
| 5P8482 | STUD-WELD (3/8-16X1.75-IN) | 6 | |
| 6S7251 | STUD-WELD (3/8-16X0.75-IN) | 5 | |
| 7E0717 | LATCH AS-DOOR | 2 | |
| 9X6442 | SEAL (246-CM) | ||
| 1146863 | WINDOW | 1 | |
| 1148139 | 2 PANEL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 14 | |
| 3W4871 | NUT (6-32-THD) | 14 | |
| 3N5979 | 3 SWITCH-ROTARY (4-POSITION)(ENGINE CONTROL) | 1 | |
| 7C4910 | 4 SEAL | 1 | |
| 0S1594 | 5 BOLT (3/8-16X1-IN) | 8 | |
| 9D2868 | 6 LENS-RED | 1 | |
| 9D2867 | 7 LENS-AMBER | 1 | |
| 2W8683 | 8 BLOCK-CONTACT | 1 | |
| 2W8798 | 9 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 4P7581 | 10 CLIP (LADDER) | 11 | |
| 4W8787 | 11 SOCKET-RELAY | 1 | |
| 7W9770 | 12 RELAY | 1 | |
| 0100741 | 13 SCREW-MACHINE (6-32X0.875-IN) | 2 | |
| 7E5923 | 14 FILM-CONTROL PANEL (LOW EMISSION RELAY IDENT) | 1 | |
| 8T4896 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 9D9161 | 16 LENS-GREEN | 1 | |
| 9D3127 | 17 BASE AS-INDICATOR LIGHT | 3 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 7N5876 | 18 LAMP (24-VOLT, 0.2-AMPERE)(CLEAR) | 3 | |
| 1112111 | 19 GUARD | 3 | |
| 6V6149 | 20 CONTROL GP-ENGINE MONITORING | 1 | |
| 7C2952 | 21 GASKET-MODULE (ENGINE CONTROL) | 1 | |
| 4F4879 | 22 BOLT (3/8-16X0.5-IN) | 4 | |
| 1209081 | 23 ROD (1/4-20-THD) | 2 | |
| 5P0537 | 24 WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 8T5447 | 25 RING-RETAINING | 2 | |
| 7E0859 | 26 POTENTIOMETER (ENGINE SPEED) | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 11 | |
| 0S0509 | 28 BOLT (3/8-16X0.75-IN) | 2 | |
| 9X9591 | 29 CONVERTER GP-ELECTRICAL (PULSE WIDTH MODULATED) | 1 | |
| 2M0849 | 30 WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 1209713 | 31 KIT-MARKER | 1 | |
| 8D2676 | 32 SWITCH AS-TOGGLE (SINGLE POLE)(IDLE, HIGH, LOW) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 1085888 | 33 CONTROL GP-ENGINE ELECTRONIC | 1 | |
| 1069182 | 34 CONTROL GP-ENG RATINGS ELEK | 1 | |
| 9S8750 | 35 NUT-FULL (1/4-20-THD) | 8 | |
| 9X9675 | 36 BRACKET-END | 4 | |
| 1151322 | 37 TERMINAL (DOUBLE) | 17 | |
| 1152538 | 38 COVER-END | 3 | |
| 1165137 | 39 SPACER (TERMINAL) | 1 | |
| 9X9616 | 40 COVER-END | 2 | |
| 1165142 | 41 TERMINAL (DOUBLE) | 5 | |
| 1165193 | 42 COVER-END | 1 | |
| 1165140 | 43 TERMINAL | 33 | |
| 1081702 | 44 TERMINAL | 48 | |
| 1210123 | 45 BAR-FIXED BRIDGE | 5 | |
| 3E5503 | 46 BAR-FIXED BRIDGE | 3 | |
| 5S4245 | 47 SCREW-MACHINE (4-40X0.5-IN) | 4 | |
| 6B4540 | 48 NUT (4-40-THD) | 4 | |
| 6B4542 | 49 LOCKWASHER | 4 | |
| 7R3029 | 50 CAP-DUST | 1 | |
| 1106197 | 51 GASKET | 1 | |
| 4P8134 | 52 CLIP (LADDER) | 8 | |
| 4W9149 | 53 SPACER (10.5X19X16.75-MM THK) | 1 | |
| 9X6772 | 54 STRAP-CABLE | 19 | |
| 1209079 | 55 TERMINAL | 5 | |
| 1213387 | 56 FILM-INFORMATION (ENGINE SUPERVISORY SYSTEM) | 1 | |
| 1166204 | 57 CONVERTER AS-SIGNAL (PWM-ANALOG) | 5 | |
| 1209080 | 58 BRACKET | 2 | |
| 5P4115 | 59 WASHER-HARD (7.2X19X2-MM THK) | 3 | |
| 8N0694 | 60 SWITCH AS-TOGGLE (SINGLE POLE)(DIAGNOSTIC RESET) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 6T6970 | 61 SWITCH AS-TOGGLE (OXYGEN SENSOR) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 3 | |
| 1209879 | 62 HARNESS AS-BOX | 1 |
