System And Components
135-3863 BOX GP-JUNCTIONS/N 7NJ1-514
Group No: 135-3863
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9D2868 | 1 LENS-RED | 1 | |
| 9D2867 | 2 LENS-AMBER | 1 | |
| 9D9161 | 3 LENS-GREEN | 1 | |
| 1096507 | 4 SWITCH AS-PUSH BUTTON (ENGINE SHUTOFF) | 1 | |
| 1112111 | 5 GUARD | 1 | |
| 7N5876 | 6 LAMP (24-VOLT, 0.2-AMPERE)(CLEAR) | 3 | |
| 9D3127 | 7 BASE AS-INDICATOR LIGHT | 3 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 1307364 | 8 CIRCUIT BREAKER AS (15-AMPERE) | 1 | |
| 9D3721 | 9 SWITCH-TOGGLE (SINGLE POLE)(DIAGNOSTIC RESET) | 1 | |
| 1111324 | 10 BLOCK-CONTACT (1-POLE) | 1 | |
| 5S4245 | 11 SCREW-MACHINE (4-40X0.5-IN) | 24 | |
| 1328485 | 12 NUT-RING | 2 | |
| 1328486 | 13 NUT-RING | 2 | |
| 1307059 | 14 HARNESS AS-WIRING | 1 | |
| 1310765 | 15 GUARD | 1 | |
| 1305733 | 16 JUNCTION BOX | 1 | |
| 1309463 | 17 FILM-CONTROL PANEL (EIS) | 1 | |
| 1307631 | 18 HARNESS AS-BOX (PANEL) | 1 | |
| 1243176 | 19 COVER | 1 | |
| 1314889 | 20 GASKET | 2 | |
| 1314888 | 21 GASKET | 1 | |
| 7R3029 | 22 CAP-DUST | 1 | |
| 1314887 | 23 GASKET | 2 | |
| 1314890 | 24 GASKET | 1 | |
| 1314891 | 25 GASKET | 1 | |
| 1314882 | 26 PLUG | 1 | |
| 4P4894 | 27 SEAL | 1 | |
| 3E5165 | 28 CAP AS-PROTECTION | 1 | |
| 4B1221 | 29 SCREW-MACHINE (8-32X0.5-IN) | 4 | |
| 1320289 | 30 PLUG-SEAL | 8 | |
| 1328487 | 31 NUT-RING | 1 | |
| 1328488 | 32 NUT-RING | 1 | |
| 1328489 | 33 NUT-RING | 1 | |
| 1355011 | 34 CAP | 2 | |
| 1313906 | PLUG AS-CONNECTOR | 1 | |
| 1314883 | PLUG AS-CONNECTOR | 1 |
