System And Components
120-8877 TANK GP-EXPANSIONType 1
Group No: 120-8877
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1139476 | 1 TUBE AS | 1 | |
| 1139479 | 2 TANK AS | 1 | |
| 6K9602 | 3 LATCH AS | 1 | |
| 2N3478 | 4 SCREW-MACHINE (10-24X0.375-IN) | 2 | |
| 4P0306 | 5 VALVE AS | 2 | |
| 6V5016 | 6 VALVE-BALL | 1 | |
| 4P2349 | 7 SEAL | 2 | |
| 4P2352 | 8 WASHER (19.844X26.59X0.794-MM THK) | 2 | |
| 3H5939 | 9 GASKET-HEAT EXCHANGER | 1 | |
| 0L1351 | 10 BOLT (3/8-16X0.875-IN) | 8 | |
| 0T0102 | 11 BOLT (3/8-16X0.625-IN) | 4 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5D1026 | 13 CLAMP-BAND | 1 | |
| 1375950 | 14 SWITCH-LEVEL (COOLANT) | 1 | |
| 2M9780 | 15 SEAL-O-RING | 1 | |
| 1153494 | 16 HOSE AS | 1 | |
| 1159128 | 17 CAP-RESERVOIR (7-PSI)(EXPANSION TANK) | 1 | |
| 1153581 | 18 TUBE AS | 1 | |
| 1153493 | 19 BRACKET | 2 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 9 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 5 | |
| 0616737 | 22 UNION-FLARED | 1 | |
| 8S8820 | 23 CLIP | 1 | |
| 9L5141 | 24 HOSE AS | 1 | |
| 1208880 | 25 TUBE AS | 1 | |
| 1162396 | 26 SUPPORT AS | 1 | |
| 1162399 | 27 SUPPORT AS | 2 | |
| 2955457 | KIT-PRESSURE CAP (EXPANSION TANK) | 1 |
