System And Components
126-5361 IGNITION GP-GAS ENGINES/N 5JD1-61
Group No: 126-5361
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6H1717 | 1 BOLT (1/2-13X1.125-IN) | 4 | |
| 5P8245 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 4P7481 | 3 SPACER (6.6X25X21-MM THK) | 4 | |
| 4P7483 | 4 BRACKET | 2 | |
| 1439607 | 5 STRAP-CABLE | 14 | |
| 4P7485 | 6 BRACKET | 12 | |
| 4P9322 | 7 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 1S9593 | STRAP-CABLE | 12 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 12 | |
| 4P8367 | ROD-SUPPORT | 13 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(120-CM) | ||
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 24 | |
| 1108359 | CONNECTOR AS (37-PIN) | 1 | |
| 9X6165 | 8 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 8F8178 | 9 BOLT (1/4-20X3.25-IN) | 4 | |
| 0T0102 | 10 BOLT (3/8-16X0.625-IN) | 16 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 1462588 | 12 SPARK PLUG | 12 | |
| 1183509 | 13 GROMMET | 4 | |
| 1253668 | 14 CONTROL GP-ENGINE MONITORING | 1 | |
| 0310243 | 15 SCREW (1/4-20X0.625-IN) | 1 | |
| 7X6035 | 16 STRAP-GROUNDING | 1 | |
| 0S1614 | 17 BOLT (1/4-20X0.5-IN) | 1 | |
| 5P0537 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1190814 | 19 GASKET | 1 | |
| 9X9838 | 20 SPACER (6.6X9.5X46.9-MM THK) | 4 | |
| 9X9896 | 21 MOUNT (ISOLATION) | 8 | |
| 1010383 | 22 GUARD AS | 1 | |
| 6V8927 | 23 BOLT-SOCKET HEAD (6-32X0.5-IN) | 4 | |
| 9B1117 | 24 LOCKWASHER | 4 | |
| 1109268 | 25 CLIP | 12 | |
| 0L1351 | 26 BOLT (3/8-16X0.875-IN) | 2 | |
| 1176512 | 27 GROMMET | 12 | |
| 1182947 | 28 BRACKET AS | 1 | |
| 1240749 | 29 TRANSFORMER GP-IGNITION | 12 | |
| 1183508 | 30 GROMMET | 2 | |
| 1182950 | 31 GROMMET | 6 | |
| 1261282 | 32 PLATE | 1 | |
| 4P7369 | HARNESS AS-WIRING (IGNITION, REPAIR) | 1 | |
| 1109268 | CLIP | 1 | |
| 1176512 | GROMMET | 1 | |
| 1439607 | STRAP-CABLE | 1 | |
| 1171254 | HARNESS AS-WIRING (IGNITION, REPAIR) | 1 |
