4P-9571 BOX GP-CONTROL PANELS/N 5JD1-19

Group No: 4P-9571

Part Number	Part Name	Qty
4P9572	1 BOX GP-CONTROL PANEL	1
7E0717	LATCH AS-DOOR	2
9X6442	SEAL (267-CM)
5P0537	WASHER-HARD (7.2X14.5X2-MM THK)	4
9P6895	PIN	4
3B5300	PIN-COTTER	4
2W8798	2 SWITCH AS-PUSH BUTTON (EMERGENCY STOP)	1
1071006	3 KIT-MARKER	1
1036267	4 FILM-INSTRUMENT PANEL	1
2W8683	5 BLOCK-CONTACT	1
1108909	6 MOUNT-FLEXIBLE	8
3E0105	7 MOUNT	3
8L8413	STRAP-CABLE (WHITE)	3
1106170	8 BUSHING (CAPPED)	1
4P1539	9 BUSHING-TERMINAL	2
5S4245	10 SCREW-MACHINE (4-40X0.5-IN)	4
6B4540	11 NUT (4-40-THD)	4
3N2050	12 FUSE (15-AMPERE)	2
5N5537	13 BLOCK-FUSE	1
7R3029	14 CAP-DUST	1
9X9675	15 BRACKET-END	4
1078345	16 BUSHING	1
3E0355	17 BLOCK-FUSE	1
3E5502	18 TERMINAL (SINGLE)	2
4P4894	19 SEAL	1
9X9616	20 COVER-END	6
9X9614	21 TERMINAL (SINGLE)	4
3B4501	22 LOCKWASHER	36
6D5801	23 LOCKNUT (8-32-THD)	32
1072482	24 GASKET	8
1043651	25 LOCKNUT (1-11-1/2 NPT THD)	1
7S1201	26 SCREW-MACHINE (8-32X0.375-IN)	32
6B4542	27 LOCKWASHER	4
9X9615	28 TERMINAL (SINGLE)	26
3E5503	29 BAR-FIXED BRIDGE	2
3E5504	30 BAR-FIXED BRIDGE	1
1106197	31 GASKET	1
9X9677	32 COVER-END	1
1057692	33 ISOLATOR	14
1057693	34 ISOLATOR	4
3E0356	35 BLOCK-TERMINAL	2
3E0357	DIODE AS	2
3E2286	36 STRIP-CONTACT	1
9U6461	37 SCREWDRIVER	1
2P6896	38 GASKET	1
7S1197	39 SCREW-MACHINE (8-32X0.5-IN)	4
9X9676	40 TERMINAL	33
3E8542	41 CONTROL GP-ENGINE MONITORING	1
2D6235	42 LOCKNUT (1/4-20-THD)	2
1B2714	43 BOLT (1/4-20X2.5-IN)	2
3N6744	WASHER	4
4P4892	44 BUSHING-TERMINAL	1
