114-8140 PANEL GP-CONTROLType 2

Group No: 114-8140

Part Number	Part Name	Qty
1145628	1 BOX AS	1
5P5906	SEAL (0.8-M)
5P8482	STUD-WELD (3/8-16X1.75-IN)	6
6S7251	STUD-WELD (3/8-16X0.75-IN)	5
7E0717	LATCH AS-DOOR	2
9X6442	SEAL (246-CM)
1146863	WINDOW	1
1148139	2 PANEL AS	1
1F0750	NUT-WELD (3/8-16-THD)	14
3W4871	NUT (6-32-THD)	14
3N5979	3 SWITCH-ROTARY (4-POSITION)(ENGINE CONTROL)	1
7C4910	4 SEAL	1
0S1594	5 BOLT (3/8-16X1-IN)	8
9D2868	6 LENS-RED	1
9D2867	7 LENS-AMBER	1
2W8683	8 BLOCK-CONTACT	1
2W8798	9 SWITCH AS-PUSH BUTTON (EMERGENCY STOP)	1
4P7581	10 CLIP (LADDER)	11
4W8787	11 SOCKET-RELAY	1
7W9770	12 RELAY	1
0100741	13 SCREW-MACHINE (6-32X0.875-IN)	2
7E5923	14 FILM-CONTROL PANEL (LOW EMISSION RELAY IDENT)	1
8T4896	15 WASHER-HARD (10.2X18.5X2.5-MM THK)	12
9D9161	16 LENS-GREEN	1
9D3127	17 BASE AS-INDICATOR LIGHT	3
6V8367	LOCKWASHER	1
6V8382	NUT-HEX (11/16-27-THD)	1
7N5876	18 LAMP (24-VOLT, 0.2-AMPERE)(CLEAR)	3
1112111	19 GUARD	3
6V6149	20 CONTROL GP-ENGINE MONITORING	1
7C2952	21 GASKET-MODULE (ENGINE CONTROL)	1
4F4879	22 BOLT (3/8-16X0.5-IN)	4
1209081	23 ROD (1/4-20-THD)	2
5P0537	24 WASHER-HARD (7.2X14.5X2-MM THK)	5
8S4950	25 CAP (FLARED 37-DEG)	1
1229457	26 POTENTIOMETER (ENGINE SPEED)	1
9S8752	27 NUT-FULL (3/8-16-THD)	12
0S0509	28 BOLT (3/8-16X0.75-IN)	2
9X4865	29 CONTROL GP-ENGINE MONITORING	1
2M0849	30 WASHER-HARD (13.5X25.5X5-MM THK)	5
1209713	31 KIT-MARKER	1
8D2676	32 SWITCH AS-TOGGLE (SINGLE POLE)(IDLE, HIGH, LOW)	1
3L8187	LOCKWASHER (3.7MM ID)	2
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	2
1085888	33 CONTROL GP-ENGINE ELECTRONIC	1
1069182	34 CONTROL GP-ENG RATINGS ELEK	1
9S8750	35 NUT-FULL (1/4-20-THD)	8
9X9675	36 BRACKET-END	4
1151322	37 TERMINAL (DOUBLE)	17
1152538	38 COVER-END	3
1165137	39 SPACER (TERMINAL)	1
9X9616	40 COVER-END	4
1165142	41 TERMINAL (DOUBLE)	5
1165193	42 COVER-END	1
1165140	43 TERMINAL	38
1081702	44 TERMINAL	48
1210123	45 BAR-FIXED BRIDGE	6
3E5503	46 BAR-FIXED BRIDGE	3
5S4245	47 SCREW-MACHINE (4-40X0.5-IN)	4
6B4540	48 NUT (4-40-THD)	4
6B4542	49 LOCKWASHER	4
7R3029	50 CAP-DUST	1
1106197	51 GASKET	1
4P8134	52 CLIP (LADDER)	9
4W9149	53 SPACER (10.5X19X16.75-MM THK)	1
9X6772	54 STRAP-CABLE	20
1209079	55 TERMINAL	5
1213387	56 FILM-INFORMATION (ENGINE SUPERVISORY SYSTEM)	1
1166204	57 CONVERTER AS-SIGNAL (PWM-ANALOG)	5
1209080	58 BRACKET	2
5P4115	59 WASHER-HARD (7.2X19X2-MM THK)	3
8N0694	60 SWITCH AS-TOGGLE (SINGLE POLE)(DIAGNOSTIC RESET)	1
3L8187	LOCKWASHER	3
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	3
6T6970	61 SWITCH AS-TOGGLE (OXYGEN SENSOR)	1
3L8187	LOCKWASHER	3
6T3631	NUT-HEX (15/32-32-THD)	2
6T3632	LOCKWASHER	1
6T3633	RING-LOCKING	1
6V8374	SCREW-MACHINE (6-32X0.25-IN)	3
1209879	62 HARNESS AS-BOX	1
1227097	63 BRACKET	1
3B4501	64 LOCKWASHER	2
6V8376	65 SCREW-MACHINE (8-32X0.25-IN)	2
1229458	66 POTENTIOMETER (1000-OHM)(ENGINE SPEED)	1
3E0356	67 BLOCK-TERMINAL	2
1152542	68 PLUG	2
1230289	69 CAPACITOR	1
3T9377	70 RESISTOR	1
8T4205	71 WASHER-HARD (7.2X14.5X2-MM THK)	4
1226951	72 TRANSDUCER-PRESSURE	1
5P8998	73 FITTING (1/4-18-THD)	1
5P4653	74 CONNECTOR	1
5B2183	75 NUT-JAM (9/16-18-THD)	1
8T5447	76 RING-RETAINING	2
5P2675	77 BOLT (1/4-20X1.75-IN)	2
1234873	78 BUSHING	1
0377692	79 NUT (2-11 1/2NPS)	1
1234875	80 BUSHING	1
7C4550	81 SEAL (ROTATING SHAFT)	1
