System And Components
4W-3283 CONVERSION GP-IGNITIONS/N 07Y4279-UP
Group No: 4W-3283
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B1915 | 1 BOLT (3/8-16X1.375-IN) | 2 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 6V3964 | 3 WASHER-HARD (8.8X25.5X5-MM THK) | 12 | |
| 8S0948 | 4 CLIP | 2 | |
| 2W3747 | 5 TRANSFORMER AS | 6 | |
| 2W5130 | 6 WIRING GP-INSTR & IGNITION | 1 | |
| 2W3748 | 6A HARNESS AS-WIRING | 1 | |
| 8L8413 | 6B STRAP-CABLE (WHITE) | 30 | |
| 8D0693 | 6C WIRE AS | 1 | |
| 5P5624 | WIRE (14-GA, BLACK) | ||
| 8M0537 | 6D TERMINAL | 1 | |
| 2L8076 | TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 1 | |
| 2W5129 | 6E WIRE AS | 1 | |
| 5P5624 | WIRE (14-GA, BLACK) | ||
| 2L8076 | 6F TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 2 | |
| 5P5624 | 6G WIRE (14-GA, BLACK) | ||
| 5P1476 | 6H TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW) | 12 | |
| 5P1477 | TERMINAL-FORK (10-GA TO 12-GA, NO. 8 SCREW)(GROUND) | 4 | |
| 2H2143 | MARKER | 1 | |
| 9M9093 | 7 FERRULE | 2 | |
| 2B2695 | 8 BOLT (5/16-18X0.875-IN) | 12 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1C0569 | 10 BOLT (5/16-18X0.5-IN) | 1 | |
| 5P0695 | 11 CONDUIT (51-CM) | ||
| 3288385 | 12 MAGNETO GP | 1 | |
| 6L5270 | 13 GASKET-MAGNETO | 1 |
