System And Components
112-4443 PANEL GP-INSTRUMENTS/N 07Y4279-UP
Group No: 112-4443
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W5994 | 1 PANEL GP-INSTRUMENT | 1 | |
| 5B2638 | 2 BOLT (3/8-16X5.25-IN) | 1 | |
| 4P8134 | 3 CLIP (LADDER) | 2 | |
| 1B9575 | 4 BOLT (5/16-18X1.56-IN) | 3 | |
| 9M1974 | 5 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 3N7239 | 6 HOSE AS | 1 | |
| 5D9231 | 7 CONNECTOR | 1 | |
| 1D4541 | 8 BOLT (5/16-18X3-IN) | 1 | |
| 3L2875 | 9 CLIP | 1 | |
| 3H9348 | 10 BOSS | 1 | |
| 8N4057 | 11 TUBE AS | 1 | |
| 6K1972 | 12 ELBOW-FLARED | 1 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8B4884 | 14 ELBOW | 1 | |
| 1S0666 | 15 ADAPTER | 1 | |
| 3B7264 | 16 FITTING | 1 | |
| 7N6369 | 17 BRACE-PANEL | 2 | |
| 3B6487 | 18 COUPLING (PIPE) | 1 | |
| 0S1615 | 19 BOLT (1/4-20X0.75-IN) | 2 | |
| 6V8185 | 20 NUT (1/4-20-THD) | 6 | |
| 5P5624 | 21 WIRE (14-GA, BLACK)(0.1M) | ||
| 3S2093 | 22 STRAP-CABLE | 3 | |
| 4B1219 | 23 SCREW-MACHINE (6-32X0.375-IN) | 1 | |
| 5H6555 | 24 LOCKWASHER | 1 | |
| 4B2040 | 25 NUT (6-32-THD) | 1 | |
| 2L8074 | 26 TERMINAL-RING (14-GA TO 16-GA, NO. 6 SCREW) | 1 | |
| 2L8077 | 27 TERMINAL-RING (14-GA TO 16-GA, 1/4-IN SCREW) | 1 | |
| 7H4155 | 28 MOUNT-FLEXIBLE | 4 | |
| 7N3001 | 29 PLATE-PANEL MOUNTING | 1 | |
| 2N2258 | 30 RIVET-POP | 7 | |
| 8T4205 | 31 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 7X2501 | 32 BOLT (1/4-20X1.25-IN) | 4 | |
| 9X6772 | 33 STRAP-CABLE | 2 |
