System And Components
131-3416 PANEL GP-INSTRUMENTS/N 07Y4279-UP
Group No: 131-3416
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1104917 | 1 BRACKET | 1 | |
| 1250847 | 2 MOUNT-FLEXIBLE | 1 | |
| 1197251 | 3 BRACKET | 1 | |
| 6K6967 | 4 ADAPTER-PIPE | 1 | |
| 4P8134 | 5 CLIP (LADDER)(FLAT) | 5 | |
| 9X6772 | 6 STRAP-CABLE | 9 | |
| 1C0569 | 7 BOLT (5/16-18X0.5-IN) | 1 | |
| 9M1974 | 8 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 4P7581 | 9 CLIP (LADDER) | 4 | |
| 2V5956 | 10 HOSE AS | 1 | |
| 6K1972 | 11 ELBOW-FLARED | 1 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 6H6699 | 13 ADAPTER (HEAT INDICATOR) | 1 | |
| 9B7237 | 14 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6V8801 | 16 NUT (3/8-16-THD) | 4 | |
| 0S1591 | 17 BOLT (3/8-16X1.5-IN) | 2 | |
| 3B1915 | 18 BOLT (3/8-16X1.375-IN)(.1M) | 1 | |
| 5D9231 | 19 CONNECTOR | 1 | |
| 6V2455 | 20 SENSOR GP-SPEED (RING) | 1 | |
| 0T0102 | 21 BOLT (3/8-16X0.625-IN) | 2 | |
| 1234567 | 22 HARNESS AS-WIRING | 1 | |
| 1250845 | 23 BOX | 1 | |
| 1197248 | 24 TACHOMETER | 1 | |
| 8L5000 | 25 SWITCH-PUSH (STARTER) | 1 | |
| 1143464 | 26 GAUGE-AIR TEMPERATURE | 1 | |
| 3N2781 | 27 GAUGE-WATER TEMPERATURE | 1 | |
| 3N2780 | 28 GAUGE-OIL PRESSURE (ENGINE) | 1 | |
| 8L5849 | 29 SWITCH-MAGNETIC (OVERSPEED) | 1 | |
| 1250846 | 30 SWITCH-PUSH BUTTON | 1 | |
| 1197253 | PANEL GP-INSTRUMENT | 1 |
