System And Components
6I-0280 BYPASS GP-EXHAUSTAN ATTACHMENT
Group No: 6I-0280
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3P7019 | 1 SEAL-METAL | 4 | |
| 4P8962 | 2 TUBE AS | 1 | |
| 4W9606 | 3 GASKET | 1 | |
| 4W9607 | 4 ELBOW-BYPASS | 1 | |
| 4W9608 | 5 FLANGE | 1 | |
| 6N0561 | 6 CLIP | 4 | |
| 7C8784 | 7 ADAPTER-EXHAUST BYPASS | 1 | |
| 7C9710 | 8 GASKET | 1 | |
| 7C9730 | 9 ELBOW-EXHAUST | 1 | |
| 7M7273 | 10 GASKET | 1 | |
| 7W9948 | 11 BRACKET | 1 | |
| 8L3598 | 12 GASKET-WOUND | 1 | |
| 3951009 | 13 STUD-TAPERLOCK | 4 | |
| 9G5127 | 14 BREATHER AS (ATMOSPHERIC) | 1 | |
| 0950955 | 15 WASHER-COPPER | 1 | |
| 1453251 | 16 BYPASS GP-EXHAUST | 1 | |
| 0619463 | 17 CONNECTOR (FLARED) | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 4 | |
| 0T0102 | 20 BOLT (3/8-16X0.625-IN) | 4 | |
| 1687800 | 21 LOCKNUT (3/8-16-THD) | 4 | |
| 3B0645 | 22 PLUG-CUP | 1 | |
| 3B1915 | 23 BOLT (3/8-16X1.375-IN) | 1 | |
| 3E2331 | 24 PLUG | 1 | |
| 4B0418 | 25 CLIP | 1 | |
| 4H0553 | 26 FITTING (SPECIAL) | 1 | |
| 4J4382 | 27 PLUG-PIPE | 1 | |
| 8T6765 | 28 PLUG-PIPE (1/4-18-THD) | 2 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P2603 | 30 STUD-TAPERLOCK (3/8-16X1.57-IN) | 4 | |
| 6B0933 | 31 SPACER (10.31X19.05X6.35-MM THK) | 1 | |
| 7L3195 | 32 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 2 | |
| 7L7262 | 33 ELBOW-FLARED | 1 | |
| 9X6458 | 34 WASHER-HARD (10.2X22.5X3-MM THK) | 8 |
