Assembly
100%

130-1539 MOUNTING GP-REFRIGERANT COMPRAN ATTACHMENT

Group No: 130-1539
Part NumberPart NameQty
9X88871 BOLT (3/4-10X3-IN)6
5P82482 WASHER-HARD (20X36.5X3.5-MM THK)12
13015423 TUBE1
13861834 PAD1
12938525 BLOCK2
12941456 PLATE-SPACER2
5P82457 WASHER-HARD (13.5X25.5X3-MM THK)12
7B32358 BOLT (1/2-13X1.375-IN)10
12957529 SUPPORT AS1
4B361410 SETSCREW-SQUARE HEAD2
1D470911 BOLT (1-8X3-IN)2
5P825012 WASHER (28X49X5-MM THK)6
129668213 SUPPORT AS1
1A806314 BOLT (3/4-10X2.5-IN)4
130135415 BLOCK2
130135516 PLATE-SPACER2
129726617 SUPPORT AS1
9X888518 BOLT (3/4-10X2.25-IN)8
120738319 FLANGE1
0S158520 BOLT (1/2-13X1.5-IN)2
1F795821 NUT-FULL (1/2-13-THD)2
138620222 BRACKET1
138850123 PIPE1
147544424 DOWEL2
9X888925 BOLT (3/4-10X3.5-IN)2
137853326 SHIM PACK (INCLUDES 13-SHIMS)2
