System And Components
178-3233 LINES GP-WATERAN ATTACHMENT
Group No: 178-3233
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S0509 | 1 BOLT (3/8-16X0.75-IN) | 4 | |
| 1K6937 | 2 ELBOW-PIPE | 2 | |
| 1L0254 | 3 ELBOW | 2 | |
| 8T6762 | 4 PLUG-PIPE (1/2-14-THD) | 2 | |
| 2N2676 | 5 BUSHING-REDUCER | 2 | |
| 3B7267 | 6 NIPPLE-PIPE | 1 | |
| 3B7741 | 7 NIPPLE-PIPE (CLOSE) | 2 | |
| 3B7745 | 8 NIPPLE-PIPE | 1 | |
| 3B7749 | 9 NIPPLE-PIPE | 2 | |
| 3D2186 | 10 ELBOW | 1 | |
| 5P0054 | 11 JOINT AS | 2 | |
| 9X7340 | SEAL | 2 | |
| 4B4609 | 12 NIPPLE-PIPE | 1 | |
| 7X7732 | 13 PLUG-PIPE | 3 | |
| 4B7770 | 14 TEE | 2 | |
| 4B9030 | 15 ELBOW | 1 | |
| 4S6399 | 16 CONNECTOR | 2 | |
| 5B4855 | 17 BUSHING-REDUCER | 1 | |
| 5J7303 | 18 ELBOW | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 28 | |
| 7B7908 | 20 NIPPLE-PIPE | 1 | |
| 9S0730 | 21 JOINT AS-TUBE | 2 | |
| 2P9773 | SEAL | 2 | |
| 9X8883 | 22 BOLT (5/8-11X2.75-IN) | 8 | |
| 9F9920 | 23 BUSHING-REDUCER | 1 | |
| 0307764 | 24 FITTING | 1 | |
| 1238580 | 25 ELBOW-FLARED | 1 | |
| 1660681 | 26 TUBE | 1 | |
| 1301574 | 27 PIPE-THREADED | 2 | |
| 1301575 | 28 PIPE-THREADED | 2 | |
| 1312414 | 29 TUBE AS | 1 | |
| 1312415 | 30 TUBE AS | 1 | |
| 1312416 | 31 TUBE AS | 1 | |
| 1312417 | 32 TUBE AS | 1 | |
| 4S8417 | 33 JOINT AS | 6 | |
| 9X7527 | SEAL | 2 | |
| 5P8247 | 34 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 1312426 | 35 TANK GP-COOLANT | 1 | |
| 1319365 | 36 COUPLING-REDUCER | 2 | |
| 1319366 | 37 ELBOW-PIPE | 1 | |
| 1319367 | 38 BUSHING-REDUCER | 1 | |
| 1320261 | 39 TUBE AS | 2 | |
| 1329496 | 40 VALVE-BALL | 3 | |
| 1329578 | 41 THERMOWELL | 1 | |
| 1363578 | 42 VALVE AS (SOLENOID VALVE) | 1 | |
| 1395642 | 43 TUBE AS | 1 | |
| 1395643 | 44 TUBE AS | 1 | |
| 1491285 | 45 ELBOW AS | 1 | |
| 1319366 | ELBOW-PIPE | 1 | |
| 1226892 | 46 HOSE-HYDRAULIC (60CM) | 1 | |
| 1241909 | COUPLING-HOSE | 1 | |
| 1241922 | COUPLING-PERMANENT | 1 | |
| 1493431 | 47 KIT-HOSE | 2 | |
| 1226891 | HOSE-HYDRAULIC (25CM) | 1 | |
| 1241906 | COUPLING-PERMANENT | 1 | |
| 1241921 | COUPLING-PERMANENT | 1 | |
| 1493475 | 48 KIT-HOSE | 2 | |
| 1226887 | HOSE (174CM) | 1 | |
| 1241950 | COUPLING-PERMANENT | 2 | |
| 1493476 | 49 FITTING AS | 1 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 1660678 | 50 TUBE | 1 | |
| 4K0367 | 51 NUT-FULL (5/8-11-THD) | 8 | |
| 3T6090 | 52 BOSS | 4 | |
| 1602576 | 53 TUBE AS | 1 | |
| 1602579 | 54 TUBE AS | 1 | |
| 1602581 | 55 BELLOWS AS | 2 | |
| 1265116 | 56 FLANGE | 2 | |
| 0S1590 | 57 BOLT (3/8-16X2-IN) | 8 | |
| 9S8752 | 58 NUT-FULL (3/8-16-THD) | 8 | |
| 1616244 | 59 GASKET | 2 | |
| 4L3862 | 60 GASKET | 4 | |
| 0S1588 | 61 BOLT (3/8-16X1.25-IN) | 8 | |
| 1649538 | 62 BRACKET | 2 |
