System And Components
178-3234 LINES GP-WATERAN ATTACHMENT
Group No: 178-3234
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S0509 | 1 BOLT (3/8-16X0.75-IN) | 4 | |
| 1K6937 | 2 ELBOW-PIPE | 2 | |
| 1L0254 | 3 ELBOW | 2 | |
| 8T6762 | 4 PLUG-PIPE (1/2-14-THD) | 2 | |
| 2N1931 | 5 ELBOW-PIPE | 1 | |
| 3B7267 | 6 NIPPLE-PIPE | 1 | |
| 3B7741 | 7 NIPPLE-PIPE (CLOSE) | 3 | |
| 3B7745 | 8 NIPPLE-PIPE | 1 | |
| 3B7749 | 9 NIPPLE-PIPE | 5 | |
| 5P0054 | 10 JOINT AS | 2 | |
| 9X7340 | SEAL | 2 | |
| 7X7732 | 11 PLUG-PIPE | 2 | |
| 4B7770 | 12 TEE | 2 | |
| 4B9030 | 13 ELBOW | 1 | |
| 4S6399 | 14 CONNECTOR | 3 | |
| 5B4855 | 15 BUSHING-REDUCER | 1 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 1602581 | 17 BELLOWS AS | 2 | |
| 4S8417 | 18 JOINT AS | 2 | |
| 9X7527 | SEAL | 2 | |
| 6B3156 | 19 NIPPLE-PIPE | 1 | |
| 6B3685 | 20 ELBOW | 1 | |
| 9F9920 | 21 BUSHING-REDUCER | 1 | |
| 9S0730 | 22 JOINT AS-TUBE | 2 | |
| 2P9773 | SEAL | 2 | |
| 9X8883 | 23 BOLT (5/8-11X2.75-IN) | 8 | |
| 0535091 | 24 REDUCER-PIPE | 2 | |
| 1301575 | 25 PIPE-THREADED | 2 | |
| 4K0367 | 26 NUT-FULL (5/8-11-THD) | 8 | |
| 5P8247 | 27 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 3T6090 | 28 BOSS | 4 | |
| 1312426 | 29 TANK GP-COOLANT | 1 | |
| 1319365 | 30 COUPLING-REDUCER | 2 | |
| 1319367 | 31 BUSHING-REDUCER | 1 | |
| 1329496 | 32 VALVE-BALL | 3 | |
| 1662041 | 33 TUBE | 1 | |
| 1329578 | 34 THERMOWELL | 1 | |
| 1343541 | 35 JOINT AS | 4 | |
| 9X7527 | SEAL | 1 | |
| 1343544 | 36 COUPLING-REDUCER | 2 | |
| 1363578 | 37 VALVE AS (SOLENOID VALVE) | 1 | |
| 1395642 | 38 TUBE AS | 1 | |
| 1395643 | 39 TUBE AS | 1 | |
| 1493010 | 40 TUBE AS | 1 | |
| 1493430 | 41 KIT-HOSE | 2 | |
| 1226892 | HOSE-HYDRAULIC | ||
| 1241909 | COUPLING-HOSE | 1 | |
| 1241922 | COUPLING-PERMANENT | 1 | |
| 1493431 | 42 KIT-HOSE | 2 | |
| 1226891 | HOSE-HYDRAULIC | 1 | |
| 1241906 | COUPLING-PERMANENT | 1 | |
| 1241921 | COUPLING-PERMANENT | 1 | |
| 1493475 | 43 KIT-HOSE | 2 | |
| 1226887 | HOSE | 1 | |
| 1241950 | COUPLING-PERMANENT | 2 | |
| 1493476 | 44 FITTING AS | 1 | |
| 1493481 | 45 TUBE AS | 1 | |
| 1493482 | 46 TUBE AS | 1 | |
| 1493485 | 47 TUBE AS | 1 | |
| 1602590 | 48 TUBE AS | 1 | |
| 1602588 | 49 FITTING AS | 1 | |
| 1602576 | 50 TUBE AS | 1 | |
| 1602579 | 51 TUBE AS | 1 | |
| 1616244 | 52 GASKET | 2 | |
| 1265116 | 53 FLANGE | 2 | |
| 0S1590 | 54 BOLT (3/8-16X2-IN) | 8 | |
| 9S8752 | 55 NUT-FULL (3/8-16-THD) | 8 | |
| 0S1588 | 56 BOLT (3/8-16X1.25-IN) | 8 | |
| 1649538 | 57 BRACKET | 2 | |
| 1887037 | 58 GASKET | 4 |
