Assembly
100%

113-6944 MOUNTING GP-REFRIGERANT COMPRAN ATTACHMENT

Group No: 113-6944
Part NumberPart NameQty
9X88871 BOLT (3/4-10X3-IN)6
5P82482 WASHER-HARD (20X36.5X3.5-MM THK)12
12069973 TUBE1
12938524 BLOCK2
12941455 PLATE-SPACER2
13785336 SHIM PACK (INCLUDES 13-SHIMS)2
4B36147 SETSCREW-SQUARE HEAD2
12935338 SUPPORT AS1
5P82459 WASHER-HARD (13.5X25.5X3-MM THK)10
7B323510 BOLT (1/2-13X1.375-IN)8
113694711 SUPPORT AS1
113694812 SUPPORT AS1
120699913 BLOCK2
145548314 PLATE2
1A806315 BOLT (3/4-10X2.5-IN)4
9X888516 BOLT (3/4-10X2.25-IN)8
120738317 FLANGE1
5P825018 WASHER (28X49X5-MM THK)2
1D470919 BOLT (1-8X3-IN)2
1K261620 SPACER (21.6X27.2X33.3-MM THK)2
0S162721 BOLT (3/4-10X4.5-IN)2
138618322 PAD1
138757723 BRACKET1
0S158524 BOLT (1/2-13X1.5-IN)2
1F795825 NUT-FULL (1/2-13-THD)2
147544426 DOWEL2
138850127 PIPE1
