System And Components
119-5974 LINES GP-WATERAN ATTACHMENT
Group No: 119-5974
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1150687 | 1 TUBE AS | 1 | |
| 1150686 | 2 TUBE AS | 1 | |
| 1150689 | 3 TUBE AS | 1 | |
| 7L4196 | 4 JOINT AS-TUBE | 6 | |
| 1150677 | 5 TUBE AS | 1 | |
| 1150683 | 6 PIPE AS | 1 | |
| 1150682 | 7 PIPE AS | 1 | |
| 3N2451 | 8 JOINT AS-TUBE | 2 | |
| 1150699 | 9 TUBE AS | 1 | |
| 1150670 | 10 TUBE | 1 | |
| 1150660 | 11 TUBE AS | 1 | |
| 1150661 | 12 TUBE AS | 1 | |
| 1150663 | 13 TUBE | 1 | |
| 1150662 | 14 TUBE | 1 | |
| 1204270 | 15 TUBE AS | 1 | |
| 1198432 | 16 TUBE AS | 1 | |
| 1198433 | 17 TUBE AS | 1 | |
| 1363578 | 18 VALVE AS (SOLENOID VALVE) | 1 | |
| 1L0254 | 19 ELBOW | 2 | |
| 4T1726 | 20 BUSHING-REDUCER | 2 | |
| 1K6937 | 21 ELBOW-PIPE | 2 | |
| 6V3541 | 22 JOINT AS-TUBE | 2 | |
| 3B6490 | 23 COUPLING-PIPE | 2 | |
| 1F6660 | 24 NIPPLE-PIPE | 1 | |
| 2D2460 | 25 NIPPLE-PIPE | 1 | |
| 1265117 | 26 FITTING AS | 1 | |
| 7B7908 | 27 NIPPLE-PIPE | 1 | |
| 3B7749 | 28 NIPPLE-PIPE | 2 | |
| 2B0858 | 29 PLUG-PIPE | 2 | |
| 3B7741 | 30 NIPPLE-PIPE (CLOSE) | 3 | |
| 1329496 | 31 VALVE-BALL | 3 | |
| 4B4845 | 32 PLUG | 3 | |
| 1492412 | 33 TUBE AS | 1 | |
| 5P8247 | 34 WASHER-HARD (17X32X3.5-MM THK) | 32 | |
| 4K0367 | 35 NUT-FULL (5/8-11-THD) | 32 | |
| 1451271 | 36 GASKET | 5 | |
| 1492411 | 37 TUBE AS | 1 | |
| 5P8248 | 38 WASHER-HARD (20X36.5X3.5-MM THK) | 8 | |
| 2J3506 | 39 NUT-FULL (3/4-10-THD) | 8 | |
| 1492687 | 40 GASKET | 2 | |
| 1490652 | 41 ORIFICE | 1 | |
| 1493199 | 42 TUBE AS | 1 | |
| 6V0436 | 43 JOINT AS-TUBE | 2 | |
| 9X7516 | SEAL | 2 | |
| 1210493 | 44 TUBE AS | 1 | |
| 1210494 | 45 TUBE AS | 1 | |
| 1493431 | 46 KIT-HOSE | 2 | |
| 1241906 | COUPLING-PERMANENT | 1 | |
| 1241921 | COUPLING-PERMANENT | 1 | |
| 1226900 | HOSE-HYDRAULIC (25CM) | ||
| 1493430 | 47 KIT-HOSE | 2 | |
| 1241909 | COUPLING-HOSE | 1 | |
| 1241922 | COUPLING-PERMANENT | 1 | |
| 1226901 | HOSE-HYDRAULIC (60CM) |
