Assembly
100%

178-3237 LINES GP-WATERAN ATTACHMENT

Group No: 178-3237
Part NumberPart NameQty
1L02541 ELBOW2
1K69372 ELBOW-PIPE2
8T67623 PLUG-PIPE (1/2-14-THD)2
2J35064 NUT-FULL (3/4-10-THD)8
3B77415 NIPPLE-PIPE (CLOSE)3
7F66546 NIPPLE-PIPE1
3B77497 NIPPLE-PIPE2
5P00548 JOINT AS4
9X7340SEAL2
3P20219 NIPPLE-PIPE1
7X773210 PLUG-PIPE3
4K036711 NUT-FULL (5/8-11-THD)32
4T172612 BUSHING-REDUCER2
5P824713 WASHER-HARD (17X32X3.5-MM THK)32
5P824814 WASHER-HARD (20X36.5X3.5-MM THK)8
6V043615 JOINT AS-TUBE2
9S2082SEAL (0.343-IN ID)2
6V354116 JOINT AS-TUBE2
9X7522SEAL2
7L419617 JOINT AS-TUBE6
9X7530SEAL2
156815918 TUBE AS1
160257219 TUBE AS1
160259820 TUBE1
115068321 PIPE AS2
161624122 TUBE AS1
160256723 BELLOWS AS2
156705824 TUBE AS1
156705725 TUBE AS1
160257426 TUBE AS1
156707027 TUBE AS1
156706928 TUBE AS1
156705529 TUBE AS1
156705630 TUBE AS1
126511731 FITTING AS1
132949632 VALVE-BALL3
136357833 VALVE AS (SOLENOID VALVE)1
145127134 GASKET5
149065135 ORIFICE1
161624236 TUBE AS1
149268737 GASKET2
161624338 TUBE AS2
149343039 KIT-HOSE2
1226892HOSE-HYDRAULIC
1241909COUPLING-HOSE2
1241922COUPLING-PERMANENT2
149343140 KIT-HOSE2
1226891HOSE-HYDRAULIC
1241906COUPLING-PERMANENT1
1241921COUPLING-PERMANENT1
5M289441 WASHER-HARD (10.2X18.5X2.5-MM THK)64
0S159042 BOLT (3/8-16X2-IN)32
9S875243 NUT-FULL (3/8-16-THD)32
149229044 GASKET4
169543045 BRACKET2
