System And Components
169-9622 LINES GP-WATERS/N 5ZZ1-99999
Group No: 169-9622
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W3146 | 1 FLANGE | 12 | |
| 4B8407 | 2 GASKET-COPPER (COPPER) | 1 | |
| 4N1320 | 3 GASKET (ADAPTER) | 2 | |
| 4P3897 | 4 MANIFOLD (INTERMEDIATE) | 2 | |
| 4W0530 | 5 RING-RETAINING | 2 | |
| 4W0531 | 6 RETAINER | 4 | |
| 7E5639 | 7 SPACER (13.88X21.34X25-MM THK) | 1 | |
| 7N3297 | 8 COVER | 1 | |
| 7N3368 | 9 GASKET | 1 | |
| 7N4932 | 10 GASKET | 1 | |
| 7N4939 | 11 BONNET-OIL COOLER | 1 | |
| 7N4940 | 12 BRACKET | 1 | |
| 7N4941 | 13 BONNET-OIL COOLER | 1 | |
| 7N4944 | 14 ELBOW | 1 | |
| 7N4945 | 15 GASKET | 1 | |
| 7N9044 | 16 TUBE | 1 | |
| 8N0386 | 17 FLANGE | 2 | |
| 8N1268 | 18 BRACKET | 9 | |
| 8N1989 | 19 TUBE | 1 | |
| 8N7639 | 20 ELBOW | 12 | |
| 8N7641 | 21 TUBE | 1 | |
| 9M4202 | 22 PLUG-DRAIN | 1 | |
| 9Y4090 | 23 HOUSING-REGULATOR | 1 | |
| 1118276 | 24 MANIFOLD (REAR, LH) | 1 | |
| 1118277 | 25 MANIFOLD (REAR, RH) | 1 | |
| 1207421 | 26 ADAPTER | 1 | |
| 1228856 | 27 GASKET | 2 | |
| 1366216 | 28 BRACKET | 2 | |
| 1419285 | 29 ELBOW | 1 | |
| 1424280 | 30 HOUSING | 1 | |
| 1539963 | 31 RING | 2 | |
| 1541616 | 32 MANIFOLD (FRONT, LH) | 1 | |
| 1541617 | 33 MANIFOLD (FRONT, RH) | 1 | |
| 1571435 | 34 CLAMP | 4 | |
| 1571437 | 35 BRACKET | 2 | |
| 1600122 | 36 ELBOW | 1 | |
| 1674334 | 37 TUBE AS | 1 | |
| 1674335 | 38 TUBE AS | 1 | |
| 1792960 | 39 SEAL-INTEGRAL | 12 | |
| 1986067 | 40 SEAL-INTEGRAL | 4 | |
| 2049598 | 41 SEAL-INTEGRAL | 12 | |
| 2301072 | 42 GASKET | 1 | |
| 0L1143 | 43 BOLT (3/8-16X2.5-IN) | 1 | |
| 0S0509 | 44 BOLT (3/8-16X0.75-IN) | 4 | |
| 0S1571 | 45 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1585 | 46 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1588 | 47 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 48 BOLT (3/8-16X1-IN) | 41 | |
| 0S1595 | 49 BOLT (1/2-13X1.25-IN) | 2 | |
| 0S1618 | 50 BOLT (5/16-18X1-IN) | 22 | |
| 0S1619 | 51 BOLT (3/8-16X3-IN) | 2 | |
| 0T0065 | 52 BOLT (3/8-16X3.5-IN) | 2 | |
| 1A5183 | 53 BOLT (3/8-16X4.75-IN) | 2 | |
| 1B7182 | 54 BOLT (5/16-18X1.25-IN) | 48 | |
| 2A4639 | 55 BOLT (3/8-16X1.625-IN) | 8 | |
| 2B2695 | 56 BOLT (5/16-18X0.875-IN) | 22 | |
| 3P0815 | 57 SEAL-O-RING | 1 | |
| 5M2894 | 58 WASHER-HARD (10.2X18.5X2.5-MM THK) | 29 | |
| 5P7701 | 59 SEAL-O-RING | 1 | |
| 5P8245 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V1454 | 61 SEAL-O-RING | 2 | |
| 6V1581 | 62 CLIP (SLOT) | 1 | |
| 6V1582 | 63 CLIP (TAB) | 1 | |
| 6V5066 | 64 SEAL-O-RING | 5 | |
| 6V6609 | 65 SEAL-O-RING | 2 | |
| 6V9027 | 66 SEAL-O-RING | 1 | |
| 6V9769 | 67 SEAL-O-RING | 12 | |
| 8T1919 | 68 SEAL-O-RING | 4 | |
| 8T6761 | 69 PLUG-PIPE (1-11-1/2 NPT THD) | 3 | |
| 8T6762 | 70 PLUG-PIPE (1/2-14-THD) | 7 | |
| 8T6765 | 71 PLUG-PIPE (1/4-18-THD) | 5 | |
| 9M1974 | 72 WASHER-HARD (8.8X16X2-MM THK) | 44 | |
| 9S4181 | 73 PLUG (1-5/16-12-THD) | 1 | |
| 9S4182 | 74 PLUG (7/16-20-THD) | 1 | |
| 9S4185 | 75 PLUG (3/4-16-THD) | 2 | |
| 9S8752 | 76 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 77 WASHER-HARD (10.2X22.5X3-MM THK) | 5 |
