141-6120 MANIFOLD GP-EXHAUST

Group No: 141-6120

Part Number	Part Name	Qty
1V7753	1 SPACER (0.546X0.841X1.75-IN THK)	4
1W7810	2 GASKET-OUTLET	1
3J5696	3 PIPE	4
4J4382	4 PLUG-PIPE (1/2-14-THD)	2
5P2603	5 STUD-TAPERLOCK (3/8-16X1.57-IN)	4
5P7128	6 BOLT-HIGH TEMPERATURE (3/8-16X2-IN)	4
7N2256	7 PLATE	2
8M2295	8 BOLT (3/8-16X1.625-IN)	2
9L7373	9 BOLT-HIGH TEMPERATURE (3/8-16X2-IN)	33
1003145	10 MANIFOLD-EXHAUST (FRONT, RH)	1
1003146	11 MANIFOLD-EXHAUST (INTERMEDIATE, RH)	3
1003147	12 MANIFOLD-EXHAUST (FRONT, LH)	1
1003148	13 MANIFOLD-EXHAUST (INTERMEDIATE, LH)	2
1003149	14 MANIFOLD-EXHAUST (REAR, LH)	1
1091086	15 SPACER (18.5X29X6-MM THK)	1
1339315	16 CLAMP-BAND	1
1350171	17 SEAL-EXHAUST	1
1350172	18 RING-EXHAUST SEAL	1
1411730	19 ELBOW	2
1411731	20 ELBOW	1
1411732	21 HOUSING-EXHAUST BYPASS	1
3116494	22 ELBOW-EXHAUST	1
1411744	23 EXHAUST AS	1
1411747	24 SHIELD	1
1411748	25 BRACKET	1
1411749	26 BRACKET	1
1411751	27 GASKET	1
1411756	28 BRACKET AS	1
3307327	30 BELLOWS AS	8
4289129	31 GASKET (SPIRAL WOUND)	8
4289130	32 GASKET (SPIRAL WOUND)	18
0S1585	34 BOLT (1/2-13X1.5-IN)	4
0S1587	35 BOLT (1/2-13X1.75-IN)	4
0S1588	36 BOLT (3/8-16X1.25-IN)	2
1683349	38 PLUG-PIPE	4
1A5822	39 BOLT (1/2-13X2.75-IN)	4
1B5355	40 NUT-FULL (3/8-16-THD)	6
1F7958	41 NUT-FULL (1/2-13-THD)	12
3E2331	42 PLUG (M18X1.5-THD)	1
3E6916	43 NUT-FULL (3/8-16-THD)	72
5M2894	44 WASHER-HARD (10.2X18.5X2.5-MM THK)	36
5P8245	45 WASHER-HARD (13.5X25.5X3-MM THK)	28
7L6443	46 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)	72
8C8491	47 WASHER-HARD (10.2X22X3-MM THK)	144
9S1374	49 BOLT (1/2-13X8-IN)	2
9S8752	50 NUT-FULL (3/8-16-THD)	2
9X8873	51 BOLT (1/2-13X2.25-IN)	2
9X8874	52 BOLT (1/2-13X3-IN)	4
4P7680	53 SPACER (10.5X22.5X15-MM THK)	8
