System And Components
396-1230 BUCKET AS-HEAVY DUTYPART OF 396-7260 BUCKET GP-HEAVY DUTY
Group No: 396-1230
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4319482 | 1 PLATE AS-HINGE (LIFT, OUTER, LH)(LIFT, OUTER, LH) | 1 | |
| 4E5591 | RETAINER | 1 | |
| 4319481 | 2 PLATE AS-HINGE (LIFT, OUTER, RH)(LIFT, OUTER, RH) | 1 | |
| 4E5591 | RETAINER | 1 | |
| 4319474 | 3 PLATE AS-HINGE (TILT, RH)(TILT, RH) | 1 | |
| 4E5591 | RETAINER | 1 | |
| 3961307 | 6 PLATE AS (LH) | 1 | |
| 2C9259 | 6A PLATE-IDENTIFICATION (CAT) | 1 | |
| 3566433 | 6B BLOCK-SHEAR | 4 | |
| 3961312 | 6C BAR | 1 | |
| 3961315 | 6D PLATE-WEAR | 1 | |
| 3961306 | 7 PLATE AS (RH) | 1 | |
| 2C9259 | 7A PLATE-IDENTIFICATION (CAT) | 1 | |
| 3566433 | 7B BLOCK-SHEAR | 4 | |
| 3961312 | 7C BAR | 1 | |
| 3961315 | 7D PLATE-WEAR | 1 | |
| 3961263 | 8 PLATE-WEAR | 1 | |
| 3961251 | 9 PLATE-WEAR | 1 | |
| 3961240 | 10 PLATE-WEAR | 4 | |
| 3961236 | 11 PLATE-WEAR | 1 | |
| 3961233 | 12 PLATE-WEAR | 3 | |
| 3055670 | 13 EDGE AS | 1 | |
| 2320138 | 13A ADAPTER-TIP (K-130, CENTER) | 5 | |
| 2320139 | 13B ADAPTER-TIP (K-130, CORNER) | 2 | |
| 2755466 | 13C BLOCK-WEAR | 2 | |
| 2831907 | 14 RIB | 4 | |
| 1386551 | 15 SHROUD (HEEL, CURVED) | 4 | |
| 1386529 | 16 SHROUD (HEEL, STRAIGHT) | 2 | |
| 1380032 | 17 COVER-ADAPTER | 22 | |
| 1380030 | 18 BASE-WEAR PLATE | 22 | |
| 1380006 | 19 RETAINER-G.E.T. | 22 |
