463-8666 BUCKET AS-HEAVY DUTY5.0-CU M (6.5-CU YD) CAPACITY

Group No: 463-8666
Part NumberPart NameQty
46473101 PLATE-WEAR2
46496225 PLATE-WEAR1
46496236 PLATE-WEAR1
46496247 PLATE-WEAR2
46496258 PLATE-WEAR1
2C92599 PLATE-IDENTIFICATION (CAT)1
157101911 SHROUD (STRAIGHT)6
157102712 SHROUD (CURVED)4
173117413 PLATE4
285325414 PLATE (PROTECTOR)1
297644516 PLATE-WEAR2
297646817 PLATE-WEAR12
297646918 PLATE-WEAR1
312569419 SETSCREW (1/4-20X0.25-IN)1
313986120 PLATE-WEAR3
464729227 EDGE AS1
232013427A ADAPTER-TIP (K-130, 2-STRAP, CENTER)2
232013527B ADAPTER-TIP (K-130, 2-STRAP, RH)2
232013627C ADAPTER-TIP (K-130, 2-STRAP, LH)2
464729328 HINGE AS1
380489028A PLATE AS2
3804892BOSS1
464729528B PLATE AS-ENGINE (OUTSIDE, LH)1
3804868BOSS1
464729628C PLATE AS-HINGE (OUTSIDE, RH)1
3804868BOSS1
464729928D PLATE AS-HINGE (INSIDE, LH)1
3804893BOSS1
464730028E PLATE AS-HINGE (INSIDE, RH)1
3804893BOSS1
