System And Components
478-6117 BUCKET AS-HEAVY DUTYPART OF 432-6219 BUCKET GP-HEAVY DUTY
Group No: 478-6117
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2853254 | 1 PLATE (PROTECTOR) | 1 | |
| 4326222 | 2 PLATE-WEAR | 1 | |
| 4326261 | 3 PLATE-WEAR | 2 | |
| 4326262 | 4 PLATE-WEAR | 2 | |
| 4326264 | 5 PLATE-WEAR | 2 | |
| 4785417 | 6 EDGE AS-CUTTING | 1 | |
| 2755465 | 6A BLOCK-WEAR | 2 | |
| 4720790 | 6B ADAPTER (2-STRAP, CENTER) | 7 | |
| 4319474 | 7 PLATE AS-HINGE (TILT, RH) | 1 | |
| 4E5591 | 7A RETAINER | 1 | |
| 4326224 | 8 HINGE AS (LIFT, OUTER, RH) | 1 | |
| 4E5591 | 8A RETAINER | 1 | |
| 4326225 | 9 HINGE AS (LIFT, OUTER, LH) | 1 | |
| 4E5591 | 9A RETAINER | 1 | |
| 4326236 | 10 PLATE AS (RH) | 1 | |
| 2C9259 | 10A PLATE-IDENTIFICATION (CAT) | 1 | |
| 3566433 | 10B BLOCK-SHEAR | 4 | |
| 4326248 | 10C PLATE-WEAR | 1 | |
| 4326249 | 10D PLATE-WEAR | 1 | |
| 4326238 | 11 PLATE AS (LH) | 1 | |
| 2C9259 | 11A PLATE-IDENTIFICATION (CAT) | 1 | |
| 3566433 | 11B BLOCK-SHEAR | 4 | |
| 4326248 | 11C PLATE-WEAR | 1 | |
| 4326249 | 11D PLATE-WEAR | 1 | |
| 1374234 | 12 PLATE-IDENTIFICATION (WORK TOOL)(BUCKET) | 1 | |
| 3125694 | 13 SETSCREW (1/4-20X0.25-IN) | 1 |
