Assembly
100%

463-8656 BUCKET AS-HEAVY DUTY ROCK4.2-CU M (5.5-CU YD) CAPACITY

Group No: 463-8656
Part NumberPart NameQty
2C92591 PLATE-IDENTIFICATION (CAT)1
15710193 SHROUD (STRAIGHT)4
15710274 SHROUD (CURVED)4
28532546 PLATE (PROTECTOR)1
29764457 PLATE-WEAR2
29764688 PLATE-WEAR12
29764699 PLATE-WEAR1
313986110 PLATE-WEAR3
464725814 EDGE AS1
472081114A ADAPTER (CENTER)2
472081214B ADAPTER (RH)2
472081314C ADAPTER (LH)2
464726015 PLATE AS-HINGE (CENTER)1
464726215A PLATE AS-HINGE (LIFT, OUTER, LH)1
464726315B PLATE AS-HINGE (LIFT, OUTER, RH)1
464726615C PLATE AS-HINGE (LIFT, INNER, LH)1
464726715D PLATE AS-HINGE (LIFT, INNER, RH)1
464727821 PLATE-WEAR2
464728225 PLATE-WEAR1
464728326 PLATE-WEAR2
464728932 PLATE-WEAR1
464729033 PLATE-WEAR1
312569434 SETSCREW (1/4-20X0.25-IN)1
