System And Components
485-4629 BUCKET AS-HEAVY DUTY ROCKPART OF 418-7024 BUCKET GP-HEAVY DUTY ROCK
Group No: 485-4629
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4791959 | 1 EDGE AS | 1 | |
| 2755467 | 1A BLOCK-WEAR | 2 | |
| 4719579 | 1B ADAPTER (K-150) | 7 | |
| 4602026 | 2 PLATE AS-HINGE (TILT, RH) | 1 | |
| 4E5591 | 2A RETAINER | 1 | |
| 4583124 | 3 BLOCK | 2 | |
| 4199558 | 4 PLATE-WEAR | 1 | |
| 4199557 | 5 PLATE-WEAR | 1 | |
| 4199556 | 6 PLATE-WEAR | 3 | |
| 4199555 | 7 PLATE-WEAR | 2 | |
| 3194054 | 8 PLATE-WEAR | 4 | |
| 1380006 | 9 RETAINER-G.E.T. | 30 | |
| 1380030 | 10 BASE-WEAR PLATE | 30 | |
| 1380033 | 11 PLATE-WEAR | 30 | |
| 1386529 | 12 SHROUD (HEEL, STRAIGHT) | 2 | |
| 1386551 | 13 SHROUD (HEEL, CURVED) | 4 | |
| 2831907 | 14 RIB | 4 | |
| 2853254 | 15 PLATE (PROTECTOR) | 1 | |
| 3125694 | 17 SETSCREW (1/4-20X0.25-IN) | 1 | |
| 4199538 | 18 PLATE AS (RH) | 1 | |
| 2C9259 | 18A PLATE-IDENTIFICATION (CAT) | 1 | |
| 3304456 | 18B BLOCK-SHEAR | 4 | |
| 4199553 | 18C PLATE-WEAR | 1 | |
| 4199554 | 18D PLATE-WEAR | 1 | |
| 4199539 | 19 PLATE AS (LH) | 1 | |
| 2C9259 | 19A PLATE-IDENTIFICATION (CAT) | 1 | |
| 3304456 | 19B BLOCK-SHEAR | 4 | |
| 4199553 | 19C PLATE-WEAR | 1 | |
| 4199554 | 19D PLATE-WEAR | 1 | |
| 1374234 | 20 PLATE-IDENTIFICATION (WORK TOOL) | 1 | |
| 4602025 | 21 PLATE AS-HINGE (TILT, LH) | 1 |
