System And Components
Assembly
100%

490-1871 BUCKET AS-HEAVY DUTY ROCKPART OF 490-1870 BUCKET GP-HEAVY DUTY ROCK

Group No: 490-1871
Part NumberPart NameQty
49630111 PLATE AS (LH)1
2C92591A PLATE-IDENTIFICATION (CAT)1
29295221B PLATE-WEAR1
31464181C PLATE-WEAR1
49630121D BAR1
24284402 WING GP-BUCKET1
49198223 PLATE AS (RH)1
2C92593A PLATE-IDENTIFICATION (CAT)1
29295223B PLATE-WEAR1
31464183C PLATE-WEAR1
49630123D BAR1
48466224 EDGE AS1
27554644A BLOCK-WEAR2
34322284B EDGE1
36838254C ADAPTER (CENTER)2
36838264D ADAPTER (RH)3
36838274E ADAPTER (LH)3
36161395 PLATE-WEAR1
31658936 PLATE1
28299647 BUSHING2
31658898 PLATE-WEAR1
28532549 PLATE (PROTECTOR)1
292952610 PLATE-WEAR2
292953811 PLATE-WEAR2
310898112 PLATE2
310898213 HINGE AS (OUTER, RH)1
4E559113A RETAINER1
310898314 HINGE AS (OUTER, LH)1
4E559114A RETAINER1
310898515 HINGE AS (INNER)2
316587216 STRIP1
316586817 PLATE AS2
316586618 PLATE2
310899719 PLATE-WEAR (RH)1
310899820 PLATE-WEAR (LH)1
310899921 PLATE-WEAR (CENTER)1
502048722 PLATE-WEAR1
310909723 PLATE2
502048624 PLATE-WEAR2
415819025 PLATE (RH)1
415821126 PLATE (LH)1
