Assembly
100%

339-1391 BUCKET AS-ROCK7.7-CU M (10.0-CU YD)

Group No: 339-1391
Part NumberPart NameQty
31256941 SETSCREW (1/4-20X0.25-IN)1
37717182 EDGE AS1
8P97702A PLATE1
13865542B ADAPTER-TIP (J-550, 2-STRAP, CENTER)2
13865552C ADAPTER-TIP (J-550, 2-STRAP, RH)(2-STRAP)3
13865562D ADAPTER-TIP (J-550, 2-STRAP, LH)(2-STRAP)3
35602363 PLATE AS (LH)1
2C92593A PLATE-IDENTIFICATION (CAT)1
34691723B PLATE-WEAR1
35602293C PLATE1
35602323D BAR1
22594824 BAR4
22595845 PLATE2
22596026 PLATE2
22847277 PAD-RUBBER2
23677598 STRIP1
25566899 PLATE6
255669710 PLATE2
356023511 PLATE AS (RH)1
2C925911A PLATE-IDENTIFICATION (CAT)1
346917211B PLATE-WEAR1
356022911C PLATE1
356023211D BAR1
255670212 PLATE1
356022813 PLATE-WEAR1
255670714 PLATE-WEAR (RH)1
255670815 PLATE-WEAR (LH)1
255670916 PLATE-WEAR (CENTER)1
257365117 PLATE2
356022718 PLATE-WEAR1
351789919 PLATE-WEAR1
351789320 PLATE6
351789221 PLATE3
351786422 HINGE AS (OUTER, LH)1
4E559122A RETAINER1
351778823 PLATE-WEAR2
351786324 HINGE AS (OUTER, RH)1
4E559124A RETAINER1
