Assembly
100%

339-1411 BUCKET AS-ROCK6.4-CU M (8.33-CU YD)

Group No: 339-1411
Part NumberPart NameQty
31256941 SETSCREW (1/4-20X0.25-IN)1
37717182 EDGE AS1
8P97702A PLATE1
13865542B ADAPTER-TIP (J-550, 2-STRAP, CENTER)2
13865552C ADAPTER-TIP (J-550, 2-STRAP, RH)3
13865562D ADAPTER-TIP (J-550, 2-STRAP, LH)3
35602533 PLATE-WEAR1
22594824 BAR4
22595845 PLATE2
22596026 PLATE2
22847277 PAD-RUBBER2
23677598 STRIP1
25566979 PLATE2
351785410 HINGE AS (OUTER, LH)1
4E559110A RETAINER1
255670211 PLATE1
351785312 HINGE AS (OUTER, RH)(OUTER, RH)1
4E559112A RETAINER1
255670713 PLATE-WEAR (RH)1
255670814 PLATE-WEAR (LH)1
255670915 PLATE-WEAR (CENTER)1
257365116 PLATE2
351785217 PLATE-WEAR1
351784318 PLATE AS (LH)1
2C925918A PLATE-IDENTIFICATION (CAT)1
351783618B BAR1
351783818C PLATE-WEAR1
351784219 PLATE AS (RH)1
2C925919A PLATE-IDENTIFICATION (CAT)1
351783619B BAR1
351783819C PLATE-WEAR1
351778820 PLATE-WEAR2
351778721 PLATE-WEAR1
