Assembly
100%

294-9000 BUCKET GP-ROCK6.4-CU M (8.3-CU YD)

Group No: 294-9000
Part NumberPart NameQty
10609121 PROTECTOR GP-SIDE BAR2
11403592 RETAINER AS7
25121803 COVER-ADAPTER (CENTER)5
25124614 COVER-ADAPTER (CORNER)2
25167305 PIN7
25717786 PLATE-WEAR (CENTER)2
25717797 PLATE-WEAR (RH)2
25717818 PLATE-WEAR (LH)2
25717829 EDGE-SEGMENT (CENTER)2
257178310 EDGE-SEGMENT (RH)2
257178411 EDGE-SEGMENT (LH)2
305567312 PLATE-WEAR1
305567413 PLATE-WEAR1
305567514 PLATE-WEAR1
478614115 BUCKET AS-HEAVY DUTY1
198109216 BOLT-PLOW (1-1/4-7X5.5-IN)24
1J494717 BOLT-PLOW (1-8X5.25-IN)9
2J350718 NUT-FULL (1-8-THD)19
3K977019 NUT-FULL (1-1/4-7-THD)24
4T661720 EDGE-CUTTING1
5P836221 NUT (1-1/4-7-THD)24
8J292822 BOLT-PLOW (1-8X3.75-IN)10
