System And Components
120-8877 TANK GP-EXPANSIONS/N CSP1-UP
Group No: 120-8877
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0306 | 1 VALVE AS | 2 | |
| 4P2349 | 2 SEAL | 2 | |
| 4P2352 | 3 WASHER (19.844X26.59X0.794-MM THK) | 2 | |
| 5D1026 | 4 CLAMP-BAND | 1 | |
| 6K9602 | 5 LATCH AS | 1 | |
| 6V5016 | 6 VALVE-BALL | 1 | |
| 9L5141 | 7 HOSE AS | 1 | |
| 1139476 | 8 TUBE AS | 1 | |
| 1139479 | 9 TANK AS | 1 | |
| 1153493 | 10 BRACKET | 2 | |
| 6V8523 | 11 HOSE (17-CM) | ||
| 1153581 | 12 TUBE AS | 1 | |
| 1159128 | 13 CAP-RESERVOIR (7-PSI)(EXPANSION TANK) | 1 | |
| 1162396 | 14 SUPPORT AS | 1 | |
| 1162399 | 15 SUPPORT AS | 2 | |
| 1208880 | 16 TUBE AS | 1 | |
| 1438540 | 17 SENSOR GP-COOLANT LEVEL | 1 | |
| 0616737 | 18 UNION-FLARED | 1 | |
| 0L1351 | 19 BOLT (3/8-16X0.875-IN) | 8 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 9 | |
| 0T0102 | 21 BOLT (3/8-16X0.625-IN) | 4 | |
| 2M9780 | 22 SEAL-O-RING | 1 | |
| 2N3478 | 23 SCREW-MACHINE (10-24X0.375-IN) | 2 | |
| 3H5939 | 24 GASKET-HEAT EXCHANGER | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8S8820 | 26 CLIP | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 5 | |
| 2254256 | 28 FILM-WARNING (HOT FLUID UNDER PRESSURE, U.S.) | 1 | |
| 2955457 | KIT-PRESSURE CAP | 1 |
