4P-9571 BOX GP-CONTROL PANELS/N CTN1-UP

Group No: 4P-9571

Part Number	Part Name	Qty
3E0105	1 MOUNT	2
3E0356	2 BLOCK-TERMINAL	2
3E0357	3 DIODE AS	2
3E2286	4 STRIP-CONTACT	1
3E5503	5 BAR-FIXED BRIDGE	2
3E8542	6 CONTROL GP-ENGINE MONITORING	1
3N6744	7 WASHER	2
3T3048	8 CLIP AS	6
4B4278	9 WASHER (10.2X20.5X1.6-MM THK)	5
4P1539	10 BUSHING-TERMINAL	1
4P9572	11 BOX-TERMINAL	1
9X6442	SEAL (267 CM)
5P0537	WASHER-HARD (7.2X14.5X2-MM THK)	4
9P6895	PIN	4
3B5300	PIN-COTTER	4
4S5719	12 SPACER (10.31X25X12.7-MM THK)	2
7R3029	13 CAP-DUST	1
8L8413	14 STRAP-CABLE (WHITE)	3
9U6461	15 SCREWDRIVER	1
9X9616	16 COVER-END	1
9X9675	17 BRACKET-END	4
1043651	18 LOCKNUT (1-11-1/2 NPT THD)	1
1081701	19 KIT-MARKER	1
1081702	20 TERMINAL	50
1096507	21 SWITCH AS-PUSH BUTTON (EMERGENCY STOP)	1
1106170	22 BUSHING (CAPPED)	1
1111323	23 BLOCK-CONTACT (1-POLE)	1
1111324	24 BLOCK-CONTACT (1-POLE)	1
1141143	25 CIRCUIT BREAKER AS (16-AMPERE)	1
1151322	26 TERMINAL (DOUBLE)	17
1152538	27 COVER-END	2
1165137	28 SPACER (TERMINAL)	1
1165140	29 TERMINAL	8
1165142	30 TERMINAL (DOUBLE)	3
1165193	31 COVER-END	1
1210816	32 MOUNT-FLEXIBLE	8
1235220	33 GASKET	1
1235223	34 PLATE	1
1314888	35 GASKET	1
1328487	36 NUT-RING	1
2027418	37 FILM (CONTROL PANEL)	1
1210817	38 GASKET	8
1B2714	39 BOLT (1/4-20X2.5-IN)	2
2P6896	40 GASKET	1
3B4501	41 LOCKWASHER	34
4P7581	42 CLIP (LADDER)	5
4P8134	43 CLIP (LADDER)	3
5P0537	44 WASHER-HARD (7.2X14.5X2-MM THK)	2
5S4245	45 SCREW-MACHINE (4-40X0.5-IN)	4
6D5801	46 LOCKNUT (8-32-THD)	16
6V8801	47 NUT (3/8-16-THD)	5
7S1197	48 SCREW-MACHINE (8-32X0.5-IN)	34
