System And Components
109-3034 WIRING GP-INSTR & IGNITIONS/N CTM1-UP
Group No: 109-3034
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C9220 | 1 PLUG AS | 1 | |
| 7W2353 | 2 PLUG AS | 8 | |
| 7W2355 | 3 PLUG AS | 1 | |
| 1043175 | 4 BOX GP-CONTROL PANEL | 1 | |
| 1093037 | 5 HARNESS AS-WIRING | 1 | |
| 1269424 | TUBE-HEAT SHRINK (3.2-MM DIA)(104-CM) | ||
| 1108714 | END-WIRE (18-GA) | 1 | |
| 1093039 | END-WIRE (12-GA) | 4 | |
| 1093038 | END-WIRE (16-GA) | 41 | |
| 1081019 | PLATE | 1 | |
| 1043651 | LOCKNUT (1-11-1/2 NPT THD) | 1 | |
| 0928226 | SPLICE | 3 | |
| 9X8243 | TUBE-HEAT SHRINK (39.9-MM DIA)(20-CM) | ||
| 9G9151 | CLIP | 1 | |
| 8T8732 | RECEPTACLE-CONNECTOR (3-PIN) | 2 | |
| 8T8731 | PLUG-CONNECTOR (3-PIN) | 1 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 8T6885 | TUBE-HEAT SHRINK (19.05-MM DIA)(12-CM) | ||
| 8L8413 | STRAP-CABLE (WHITE) | 75 | |
| 7X1443 | PROTECTOR | 2 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 6I0755 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 5P6009 | TUBE-HEAT SHRINK (9.52-MM DIA)(7-DM) | ||
| 4P4892 | BUSHING-TERMINAL | 1 | |
| 4P1539 | BUSHING-TERMINAL | 1 | |
| 2L8074 | TERMINAL-RING (14-GA TO 16-GA, NO. 6 SCREW) | 2 | |
| 5S7433 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 9D5421 | RECEPTACLE AS-CONNECTOR (10-PIN) | 1 | |
| 1080335 | PLUG AS-CONNECTOR (37-PIN) | 1 | |
| 1352942 | PLUG AS-CONNECTOR (54-PIN) | 1 | |
| 1L6561 | 6 PLUG | 1 |
