System And Components
116-1856 PUMP GP-AUXILIARY WATERS/N CNR1-UP
Group No: 116-1856
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1161855 | 1 SHAFT-WATER PUMP | 1 | |
| 1N8327 | 2 BODY | 1 | |
| 2L8509 | 3 RING-LOCK | 1 | |
| 1N8326 | 4 SHIM (0.005-IN THK) | 1 | |
| 5S0003 | 5 NUT (5/16-18-THD) | 4 | |
| 9M1974 | 6 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 2K0564 | 7 LOCKNUT (1/2-20-THD) | 1 | |
| 5H8633 | 8 LOCKNUT (3/8-24-THD) | 1 | |
| 8L4000 | 9 KEY | 1 | |
| 1N8321 | 10 IMPELLER | 1 | |
| 1N8322 | 11 HOUSING AS | 1 | |
| 5M6214 | 11A PLUG (1/8-27 PTF) | 1 | |
| 8L4013 | 12 GASKET | 1 | |
| 8L4042 | 13 SEAL AS | 1 | |
| 8L4024 | 14 SLINGER | 1 | |
| 2246784 | 15 SEAL-OIL | 1 | |
| 6B0926 | 16 BALL BEARING | 1 | |
| 1N8325 | 17 SPACER (0.6X0.73X1.129-IN THK) | 1 | |
| 1N8320 | 18 BALL BEARING | 1 | |
| 2R1230 | 19 RING-RETAINING | 1 | |
| 1N9901 | 20 SPACER (0.6X0.75X0.354-IN THK) | 1 | |
| 7N5306 | 21 GEAR-WATER PUMP (20-TEETH) | 1 | |
| 1B8702 | 22 KEY-WOODRUFF | 1 | |
| 4B4280 | 23 WASHER (13.5X27X2.5-MM THK) | 1 |
