System And Components
2W-4872 IGNITION GP-GAS ENGINES/N CNR1-UP
Group No: 2W-4872
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W2479 | 1 WIRE AS-PLUG | 6 | |
| 2W3747 | 2 TRANSFORMER AS | 6 | |
| 2N2839 | 3 PLUG AS-SPARK | 6 | |
| 1083515 | GASKET-PLUG | 1 | |
| 7W6492 | 4 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8M8157 | 5 SEAL-O-RING | 6 | |
| 3288385 | 6 MAGNETO GP | 1 | |
| 6L5270 | 7 GASKET-MAGNETO | 1 | |
| 3B1915 | 8 BOLT (3/8-16X1.375-IN) | 1 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 7N2587 | 10 GEAR GP-MAGNETO DRIVE (14-TEETH) | 1 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 1 | |
| 8T6764 | 12 PLUG-PIPE (1/8-27-THD) | 1 | |
| 0S1619 | 13 BOLT (3/8-16X3-IN) | 2 | |
| 4N4057 | 14 ADAPTER | 1 | |
| 8M5253 | 15 SEAL-O-RING | 1 | |
| 8M5248 | 16 SEAL-O-RING | 1 | |
| 6V3964 | 17 WASHER-HARD (8.8X25.5X5-MM THK) | 12 | |
| 2B2695 | 18 BOLT (5/16-18X0.875-IN) | 12 | |
| 4P7581 | 19 CLIP (LADDER) | 3 | |
| 9X6772 | 20 STRAP-CABLE | 3 | |
| 6I2762 | 21 HARNESS AS-WIRING (IGNITION) | 1 | |
| 3E6493 | PLUG AS-CONNECTOR | 1 | |
| 5P1476 | TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW) | 6 | |
| 5P1478 | TERMINAL-FORK (10-GA TO 12-GA, NO. 10 SCREW) | 6 | |
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 3 | |
| 2L8076 | TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 1 | |
| 9X6458 | 23 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 1 | |
| 4P1650 | 27 COVER | 1 | |
| 1H7339 | 28 SEAL-O-RING | 1 |
