System And Components
2W-6617 IGNITION GP-GAS ENGINES/N CNR1-UP
Group No: 2W-6617
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7581 | 1 CLIP (LADDER) | 3 | |
| 2N2839 | 2 PLUG AS-SPARK | 6 | |
| 1083515 | GASKET-PLUG | 1 | |
| 7W2479 | 3 WIRE AS-PLUG | 6 | |
| 9X6458 | 4 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 8M8157 | 5 SEAL-O-RING | 6 | |
| 3288385 | 7 MAGNETO GP | 1 | |
| 6L5270 | 8 GASKET-MAGNETO | 1 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 1 | |
| 9X6772 | 10 STRAP-CABLE | 3 | |
| 2W3747 | 11 TRANSFORMER AS | 6 | |
| 7N2587 | 12 GEAR GP-MAGNETO DRIVE (14-TEETH) | 1 | |
| 6V3964 | 13 WASHER-HARD (8.8X25.5X5-MM THK) | 12 | |
| 2B2695 | 14 BOLT (5/16-18X0.875-IN) | 12 | |
| 6I2762 | 15 HARNESS AS-WIRING (IGNITION) | 1 | |
| 3E6493 | PLUG AS-CONNECTOR | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 3B1915 | 16 BOLT (3/8-16X1.375-IN) | 1 | |
| 4P1650 | 18 COVER | 1 | |
| 1H7339 | 19 SEAL-O-RING | 1 |
