System And Components
9Y-9812 CARBURETOR GPS/N KAR1-UP
Group No: 9Y-9812
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1598337 | 1 CARBURETOR GP | 1 | |
| 5H1351 | 2 PIN-SPRING | 1 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 3B1915 | 5 BOLT (3/8-16X1.375-IN) | 8 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 4 | |
| 4L4642 | 7 GASKET | 1 | |
| 9Y4169 | 8 TUBE AS | 1 | |
| 7C8258 | 9 TUBE AS | 1 | |
| 9S8752 | 10 NUT-FULL (3/8-16-THD) | 4 | |
| 7C1147 | 11 THROTTLE GP | 1 | |
| 9Y1296 | 11A LEVER AS-THROTTLE | 1 | |
| 6L5296 | 11B SCREW-PIN (10-32X0.75-IN) | 1 | |
| 6L5287 | 11C DISC-THROTTLE | 1 | |
| 6L5285 | 11D SHAFT-THROTTLE | 1 | |
| 6L5286 | 11E LEVER AS-STOP | 1 | |
| 5L1150 | 12 GASKET | 2 | |
| 7W7263 | 13 ADAPTER | 1 | |
| 5S0003 | 14 NUT (5/16-18-THD) | 4 | |
| 2N8630 | 15 GASKET | 1 | |
| 7L3201 | 16 JOINT AS-TUBE | 1 | |
| 8L8585 | SEAL | 2 | |
| 1B2790 | 17 BOLT (5/16-18X1.375-IN) | 4 | |
| 9Y5304 | KIT-BEARING | 1 |
