269-9253 IGNITION GP-GAS ENGINES/N KAR1-UP

Group No: 269-9253

Part Number	Part Name	Qty
4P7581	1 CLIP (LADDER)	4
9X6772	2 STRAP-CABLE	12
4W5439	3 TRANSFORMER AS	6
7C9722	4 BRACKET	2
2502149	5 WIRE AS	6
7E0079	6 SEAL	6
1043170	7 PLUG AS-SPARK	6
1083515	GASKET-PLUG	1
8T6765	8 PLUG-PIPE (1/4-18-THD)	1
9M1974	9 WASHER-HARD (8.8X16X2-MM THK)	11
1C0569	10 BOLT (5/16-18X0.5-IN)	11
1636164	11 CONTROL GP-TIMING	1
1930995	12 HARNESS AS-WIRING (IGNITION)	1
6D8149	PLUG AS-CONNECTOR (10-PIN)	1
7T3272	RECEPTACLE-CONNECTOR (6-PIN)	1
8L8413	STRAP-CABLE (WHITE)	6
8T8737	PLUG-SEAL	3
0928226	SPLICE	3
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(9-CM)
1311477	TERMINAL AS	12
5P1476	TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
2L8076	TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	4
8S8158	13 SEAL-WIRE	1
5P6025	14 LOCKWIRE (0.1-M)
4P8134	15 CLIP (LADDER)	4
0S0509	16 BOLT (3/8-16X0.75-IN)	1
1958034	17 BRACKET	1
1166806	18 SENSOR GP-SPEED (TIMING)	1
4B8407	19 GASKET-COPPER	1
0S1589	20 BOLT (5/8-11X1.75-IN)	2
5P8247	21 WASHER-HARD (17X32X3.5-MM THK)	1
4B4863	22 WASHER (4.7X11X1.2-MM THK)	8
4B2043	23 NUT (8-32-THD)	4
9X8486	24 SCREW-MACHINE (8-32X0.75-IN)	4
1764703	25 WASHER (17X30X8-MM THK)	1
1958035	26 HARNESS AS-WIRING (TIMING)	1
5P6009	TUBE-HEAT SHRINK (9.52-MM DIA)(0.1-M)
6I0755	PLUG AS-CONNECTOR (3-PIN)	1
8T6342	TUBE-HEAT SHRINK (3.2-MM DIA)(8-CM)
8T8729	PIN-CONNECTOR (16-GA TO 18-GA)	3
9X4385	PLUG AS-CONNECTOR (6-PIN)	1
0928226	SPLICE	2
1030213	RECEPTACLE AS-CONNECTOR (70-PIN)	1
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(6-CM)
2L8076	TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW)	1
2146132	27 TUBE	6
5P8068	28 SEAL-O-RING	6
