System And Components
344-5867 IGNITION GP-GAS ENGINES/N KAR1-UP
Group No: 344-5867
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C0569 | 1 BOLT (5/16-18X0.5-IN) | 11 | |
| 2S6024 | 2 FUSE (5-AMPERE) | 2 | |
| 4B8407 | 3 GASKET-COPPER | 1 | |
| 4P7581 | 4 CLIP (LADDER) | 3 | |
| 4W5439 | 5 TRANSFORMER AS | 6 | |
| 2146132 | 6 TUBE | 6 | |
| 5P8068 | 7 SEAL-O-RING | 6 | |
| 7C9722 | 8 BRACKET | 2 | |
| 7E0079 | 9 SEAL | 6 | |
| 1832447 | 10 HARNESS AS-WIRING | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 6D8149 | PLUG AS-CONNECTOR (10-PIN) | 1 | |
| 2L8052 | TERMINAL-RING (6-GA, 3/8-IN SCREW) | 1 | |
| 2L8060 | TERMINAL-RING (8-GA, 3/8-IN SCREW) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 6 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 5P1476 | TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW) | 13 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(39-CM) | ||
| 8T6342 | 11 TUBE-HEAT SHRINK (3.2-MM DIA)(2-CM EACH) | ||
| 8T6765 | 12 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9G2731 | 13 HOLDER AS-FUSE | 2 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 11 | |
| 9X6772 | 15 STRAP-CABLE | 3 | |
| 1043170 | 16 PLUG AS-SPARK | 6 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1166806 | 17 SENSOR GP-SPEED (TIMING) | 1 | |
| 1636110 | 18 HARNESS AS-SENSOR | 1 |
