System And Components
394-8501 RADIATOR & FAN GPS/N KAP1-UP
Group No: 394-8501
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3K3318 | 1 BOLT (3/4-10X4.25-IN) | 2 | |
| 6N4371 | 2 FAN GP-BLOWER | 1 | |
| 2056598 | 3 BRACKET | 2 | |
| 2056601 | 4 BRACE | 2 | |
| 2056621 | 5 LINES GP-WATER (RADIATOR, LOWER) | 1 | |
| 3941400 | 7 LINES GP-WATER (AFTERCOOLER) | 1 | |
| 3948500 | 8 RADIATOR GP | 1 | |
| 3H5389 | 9 U-BOLT | 1 | |
| 6V8182 | 14 NUT (3/4-10-THD) | 4 | |
| 6V8189 | 15 NUT (5/16-18-THD) | 2 | |
| 7X0346 | 16 BOLT (5/8-11X2-IN) | 4 | |
| 7X0365 | 17 BOLT (3/4-10X1.5-IN) | 2 | |
| 7X0448 | 18 NUT (5/8-11-THD) | 4 | |
| 7X0515 | 19 WASHER-HARD (17X35X5-MM THK) | 8 | |
| 7X0582 | 20 WASHER-HARD (20X44.5X6-MM THK) | 2 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4994 | 22 WASHER-HARD (20X36.5X3.5-MM THK) | 4 |
