System And Components
7N-4360 DRIVE GP-GOVERNORAN ATTACHMENT
Group No: 7N-4360
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W9112 | 1 HOUSING AS-DRIVE | 1 | |
| 2F4547 | 1A DOWEL | 4 | |
| 8L6376 | 1B BUSHING | 1 | |
| 2P0220 | 2 GASKET-PUMP | 1 | |
| 0S1589 | 3 BOLT (5/8-11X1.75-IN) | 2 | |
| 3B1915 | 4 BOLT (3/8-16X1.375-IN) | 3 | |
| 7N2374 | 5 SHAFT AS-GOVERNOR DRIVE | 1 | |
| 7L0150 | COLLAR | 1 | |
| 1W0936 | 6 GEAR-GOVERNOR DRIVE (29-TEETH) | 1 | |
| 8B2377 | 7 BOLT (1/4-20X2-IN) | 1 | |
| 3S1208 | 8 WASHER-CONICAL | 1 | |
| 7N2372 | 9 SHAFT-RACK CONTROL | 1 | |
| 3N4293 | 10 LEVER-GOVERNOR | 1 | |
| 2R0504 | 11 NUT (5/16-18-THD) | 1 | |
| 3N4292 | 12 BOLT | 1 | |
| 8M2337 | 13 WASHER (7.2X24.5X3-MM THK) | 1 | |
| 5M6228 | 14 BEARING AS-NEEDLE | 1 | |
| 3H2023 | 15 DOWEL | 1 | |
| 1F4622 | 16 BEARING AS-NEEDLE | 1 | |
| 2M2489 | 17 SEAL-LIP TYPE | 1 | |
| 7N4361 | 18 LEVER AS-OUTPUT | 1 | |
| 5B4688 | 18A PIN-TAPERED | 1 | |
| 2N2170 | 18B LEVER-GOVERNOR OUTPUT | 1 | |
| 7N2977 | 18C SHAFT-GOVERNOR OUTPUT | 1 | |
| 5P3426 | 19 ELBOW | 1 | |
| 6K1972 | 20 ELBOW-FLARED | 1 | |
| 7N3093 | 21 TUBE AS | 1 | |
| 3J7354 | 22 SEAL-O-RING | 1 |
