System And Components
7N-2375 GOVERNOR GPAN ATTACHMENT
Group No: 7N-2375
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8883 | 2 SHAFT | 1 | |
| 8M9140 | 3 SPRING | 1 | |
| 1146306 | 4 PIN-DOWEL | 1 | |
| 2P8697 | 5 GASKET | 1 | |
| 1A9579 | 7 BOLT (5/16-18X1.5-IN) | 1 | |
| 1146305 | 8 WASHER-SPRING | 1 | |
| 2N2168 | 9 SCREW-ADJUSTMENT | 1 | |
| 2P8737 | 10 HOUSING AS-GOVERNOR | 1 | |
| 9S0798 | 10A BUSHING | 1 | |
| 8S0134 | 10B BUSHING | 1 | |
| 4F4585 | 10C PLUG-CORE | 1 | |
| 8M8403 | 10D SPRING-GUIDE | 1 | |
| 2S7905 | 10E PLUG-PIPE | 2 | |
| 9M6302 | 11 WASHER-SPECIAL | 2 | |
| 1W4640 | 12 SEAT-SPRING | 1 | |
| 1W1132 | 13 WEIGHT AS-GOVERNOR | 1 | |
| 1S5440 | 13A DOWEL | 2 | |
| 1144811 | 14 SLEEVE-VALVE | 1 | |
| 1H5514 | 15 BOLT (5/16-18X1.625-IN) | 6 | |
| 0S1618 | 16 BOLT (5/16-18X1-IN) | 1 | |
| 3K0810 | 17 RING-LOCK | 1 | |
| 8M8739 | 18 BOLT-LOAD STOP | 1 | |
| 7N7163 | 19 COVER | 1 | |
| 0S1615 | 20 BOLT (1/4-20X0.75-IN) | 3 | |
| 7B8105 | 21 RING-LOCK | 1 | |
| 8H9181 | 22 SPRING-BUMPER | 1 | |
| 6N3504 | 23 SEAT-GOVERNOR SPRING | 1 | |
| 9S5393 | 24 PLUG | 1 | |
| 2P8763 | 25 GASKET | 1 | |
| 2P8630 | 27 DOWEL | 1 | |
| 4W7654 | 29 BOLT (1/4-28X1.25-IN) | 1 | |
| 1144812 | 30 RISER-GOVERNOR | 1 | |
| 2W1491 | 31 LEVER-CONTROL | 1 | |
| 1464244 | 32 PISTON AS-SERVO | 1 | |
| 5P9757 | SEAL-O-RING | 1 | |
| 1S4741 | CYLINDER-SERVO | 1 | |
| 8N6977 | SLEEVE | 1 | |
| 9M6293 | 33 LOCK-CYLINDER | 1 | |
| 7M7193 | 34 RACE-THRUST BEARING | 2 | |
| 7M7219 | 35 BEARING-THRUST | 1 | |
| 7D5473 | 36 BOLT-SOCKET HEAD (8-32X0.75-IN) | 1 | |
| 7N1651 | 37 COLLAR-LOAD STOP | 1 | |
| 6N9339 | 38 GASKET-GOVERNOR HOUSING | 1 | |
| 9S4671 | 39 SEAL-LIP TYPE | 1 | |
| 2B2695 | 40 BOLT (5/16-18X0.875-IN) | 1 | |
| 9L9578 | 41 BOLT (5/16-18X1.5-IN) | 1 | |
| 5L8991 | 43 GASKET-COVER | 1 | |
| 0S1617 | 44 BOLT (5/16-18X0.75-IN) | 1 | |
| 5L8992 | 45 COVER-ADJUSTMENT | 1 | |
| 5P6945 | 46 BOLT (1/4-20X1.125-IN) | 1 | |
| 4B9747 | 47 WASHER (0.266X0.375X0.031-IN THK) | 1 |
