System And Components
174-6918 LINES GP-WATER (CHG -00, -01, -01D1)Type 1
Group No: 174-6918
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W7020 | 1 RING-RETAINING | 1 | |
| 2W4032 | 2 RETAINER | 2 | |
| 6S4931 | 3 PLATE | 1 | |
| 1339637 | 4 BRACKET | 1 | |
| 1737075 | 5 TUBE AS | 1 | |
| 1737076 | 6 TUBE AS | 1 | |
| 1744803 | 7 CLAMP AS | 2 | |
| 1747013 | 8 RING | 1 | |
| 1757770 | 9 ADAPTER | 1 | |
| 1765880 | 10 CONNECTOR | 1 | |
| 0S1590 | 11 BOLT (3/8-16X2-IN) | 1 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 4 | |
| 1069586 | 13 SEAL-O-RING | 1 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 2 | |
| 2A4639 | 15 BOLT (3/8-16X1.625-IN) | 2 | |
| 3V3308 | 16 WASHER-HARD (10.2X20.5X2.5-MM THK) | 14 | |
| 4K0367 | 17 NUT-FULL (5/8-11-THD) | 1 | |
| 5P8247 | 18 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 6K5535 | 19 CLIP (SLOT) | 2 | |
| 6K5536 | 20 CLIP (TAB) | 2 | |
| 6L7817 | 21 SEAL-O-RING | 2 | |
| 6V1903 | 22 SEAL-O-RING | 4 | |
| 7L6580 | 23 SEAL-O-RING | 1 | |
| 8T6762 | 24 PLUG-PIPE (1/2-14-THD) | 1 | |
| 9S4188 | 25 PLUG | 2 | |
| 9S8752 | 26 NUT-FULL (3/8-16-THD) | 5 | |
| 9X8883 | 27 BOLT (5/8-11X2.75-IN) | 1 |
