System And Components
125-3905 LINES GP-GAS (CHG -00 THRU -02, -04, -05, -05D1)
Group No: 125-3905
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I2394 | 1 TUBE AS | 6 | |
| 6I2658 | 2 TUBE AS-MANIFOLD | 1 | |
| 7E8217 | 3 TUBE AS | 6 | |
| 8C6868 | 4 CONNECTOR | 12 | |
| 1054046 | 5 TUBE AS | 6 | |
| 1182735 | 6 VALVE-NEEDLE | 6 | |
| 1290796 | 7 BRACKET AS | 3 | |
| 1290797 | 8 BRACKET AS | 1 | |
| 1317752 | 9 ADAPTER AS | 1 | |
| 2659703 | 10 BRACKET AS | 1 | |
| 2722504 | 11 PLATE | 1 | |
| 0S1571 | 12 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 24 | |
| 0S1590 | 14 BOLT (3/8-16X2-IN) | 7 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 11 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 4 | |
| 1249633 | 17 CLIP (SLOT) | 1 | |
| 3V3308 | 18 WASHER-HARD (10.2X20.5X2.5-MM THK) | 39 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8211 | 20 SEAL-O-RING | 6 | |
| 6J2244 | 21 SEAL-O-RING | 12 | |
| 6V5039 | 22 CLIP (SLOT) | 3 | |
| 6V5040 | 23 CLIP (TAB) | 3 | |
| 6V5049 | 24 SEAL-O-RING | 13 | |
| 6V8002 | 25 SEAL-O-RING | 1 | |
| 6V8636 | 26 CONNECTOR | 6 | |
| 8L2779 | 27 SEAL-O-RING | 24 | |
| 8M7145 | 28 WASHER (10.2X28.5X5-MM THK) | 5 | |
| 8M9024 | 29 WASHER-HARD (10.2X22.5X5-MM THK) | 12 | |
| 8T0075 | 30 CONNECTOR | 6 | |
| 9D6196 | 31 CLIP (SLOT) | 2 | |
| 9D6197 | 32 CLIP (TAB) | 2 | |
| 9L9132 | 33 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S4191 | 34 PLUG (9/16-18-THD) | 1 | |
| 9S8752 | 35 NUT-FULL (3/8-16-THD) | 11 |
