Assembly
100%

159-2047 LINES GP-GAS (CHG -00, -01, -01D1, -02)

Group No: 159-2047
Part NumberPart NameQty
0S15881 BOLT (3/8-16X1.25-IN)24
0S15902 BOLT (3/8-16X2-IN)6
0S15913 BOLT (3/8-16X1.5-IN)11
0S15944 BOLT (3/8-16X1-IN)4
3V33085 WASHER-HARD (10.2X20.5X2.5-MM THK)32
5P82116 SEAL-O-RING6
6I23947 TUBE AS6
15920468 ADAPTER AS1
6I26589 TUBE AS-MANIFOLD1
6J224410 SEAL-O-RING12
6V503911 CLIP (SLOT)3
6V504012 CLIP (TAB)3
6V504913 SEAL-O-RING13
6V800214 SEAL-O-RING1
6V863615 CONNECTOR6
7E821716 TUBE AS6
8C686817 CONNECTOR12
8L277918 SEAL-O-RING24
8M714519 WASHER (10.2X28.5X5-MM THK)4
8M902420 WASHER-HARD (10.2X22.5X5-MM THK)12
8T007521 CONNECTOR6
9D619622 CLIP (SLOT)1
9D619723 CLIP (TAB)1
9L913224 WASHER-HARD (10.2X25.5X2.5-MM THK)8
9S419125 PLUG (9/16-18-THD)1
9S875226 NUT-FULL (3/8-16-THD)10
129079627 BRACKET AS3
129079728 BRACKET AS1
105404629 TUBE AS6
110835830 VALVE-NEEDLE6
124963331 CLIP (SLOT)1
