System And Components
6I-2724 LINES GP-GAS (CHG -00 THRU -08)
Group No: 6I-2724
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I2394 | 1 TUBE AS | 6 | |
| 5P8211 | SEAL-O-RING | 6 | |
| 0S1590 | 2 BOLT (3/8-16X2-IN) | 6 | |
| 8M9024 | WASHER-HARD (10.2X22.5X5-MM THK) | 12 | |
| 6I2397 | 3 TUBE AS | 1 | |
| 6V8002 | SEAL-O-RING | 1 | |
| 0S1588 | 4 BOLT (3/8-16X1.25-IN) | 24 | |
| 3V3308 | 5 WASHER-HARD (10.2X20.5X2.5-MM THK) | 32 | |
| 6I2658 | 6 TUBE AS-MANIFOLD | 1 | |
| 1290796 | 7 BRACKET AS | 3 | |
| 1290797 | 8 BRACKET AS | 1 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 4 | |
| 6V5039 | 10 CLIP (SLOT) | 3 | |
| 6V5040 | CLIP (TAB) | 3 | |
| 1182735 | 11 VALVE-NEEDLE | 6 | |
| 9D6197 | 12 CLIP (TAB) | 1 | |
| 9D6196 | CLIP (SLOT) | 1 | |
| 1054046 | 13 TUBE AS | 6 | |
| 0S1591 | 14 BOLT (3/8-16X1.5-IN) | 11 | |
| 9S8752 | 15 NUT-FULL (3/8-16-THD) | 10 | |
| 8C6868 | 16 CONNECTOR | 12 | |
| 1173913 | 17 ORIFICE | 6 | |
| 6J2244 | SEAL-O-RING | 12 | |
| 9S4191 | 18 PLUG (9/16-18-THD) | 9 | |
| 6V8636 | 19 CONNECTOR | 6 | |
| 7E8217 | 20 TUBE AS | 6 | |
| 8T0075 | 21 CONNECTOR | 6 | |
| 8L2779 | 22 SEAL-O-RING | 24 | |
| 1249633 | 23 CLIP (SLOT) | 1 | |
| 6V5049 | 24 SEAL-O-RING | 21 | |
| 8M7145 | 25 WASHER (10.2X28.5X5-MM THK) | 4 | |
| 9L9132 | 26 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 |
