System And Components
4P-8407 DRIVE GP-MAGNETO (CHG -04)Type 2
Group No: 4P-8407
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S4191 | 1 PLUG (9/16-18-THD) | 1 | |
| 0S1594 | 2 BOLT (3/8-16X1-IN) | 4 | |
| 3V3308 | 3 WASHER-HARD (10.2X20.5X2.5-MM THK) | 10 | |
| 8K4909 | 4 PLATE | 1 | |
| 0S1588 | 5 BOLT (3/8-16X1.25-IN) | 4 | |
| 7C7362 | 6 GASKET | 1 | |
| 6V5060 | 7 SEAL-O-RING | 1 | |
| 1277361 | 8 PLATE AS | 1 | |
| 1W7117 | DOWEL-HOLLOW | 2 | |
| 5B2638 | 9 BOLT (3/8-16X5.25-IN) | 2 | |
| 6V5135 | 10 SETSCREW-SOCKET (7/16-20X0.375-IN) | 1 | |
| 7E5486 | 11 GEAR (29-TEETH) | 1 | |
| 1307641 | 12 HOUSING AS | 1 | |
| 8F6800 | 13 BUSHING-TERMINAL | 2 | |
| 1W8929 | 14 COUPLING | 1 | |
| 0S1571 | 15 BOLT (3/8-16X1.75-IN) | 1 | |
| 1A1460 | 16 BOLT (1/2-13X2-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 7E5485 | 17 GEAR (116-TEETH) | 1 | |
| 1277362 | 18 PLATE | 1 | |
| 0S1614 | 19 BOLT (1/4-20X0.5-IN) | 2 | |
| 5P0537 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 6V5049 | 21 SEAL-O-RING | 2 | |
| 7J9108 | 22 SEAL-O-RING | 1 | |
| 8C6758 | 23 CONNECTOR | 1 | |
| 8C7312 | 24 ADAPTER | 1 | |
| 0307972 | 25 ELBOW | 1 | |
| 1409348 | 26 TUBE AS | 1 |
