System And Components
146-4287 IGNITION GP-GAS ENGINE (CHG -09, -09D1)VARIABLE TIMING
Group No: 146-4287
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1590 | 1 BOLT (3/8-16X2-IN) | 3 | |
| 4B3388 | 2 BOLT (5/16-18X1.125-IN) | 18 | |
| 0S1621 | 3 BOLT (1/2-13X1-IN) | 2 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 1 | |
| 3P0650 | 5 SEAL-O-RING | 6 | |
| 3V3308 | 6 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 4S1962 | 7 CLIP (LOOP) | 1 | |
| 5P6025 | 8 LOCKWIRE (1.9M) | ||
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V3830 | 10 SEAL-O-RING | 6 | |
| 7E3056 | 11 HARNESS AS-WIRING (IGNITION) | 6 | |
| 4G2544 | CONNECTOR-PLUG | 1 | |
| 9D3955 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 7E8362 | 12 TUBE AS | 6 | |
| 7H3937 | 13 LOCKWASHER | 1 | |
| 7W4377 | 14 TRANSFORMER | 6 | |
| 1609912 | 15 SEAL-INTEGRAL | 6 | |
| 8S8158 | 16 SEAL-WIRE | 19 | |
| 8T1895 | 17 CLIP (SLOT) | 3 | |
| 8T1896 | 18 CLIP (TAB) | 3 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 18 | |
| 0910081 | 20 SPACER (10.5X20X10-MM THK) | 3 | |
| 2074509 | 21 EXTENSION AS | 6 | |
| 1948518 | 22 SPARK PLUG | 6 | |
| 2275965 | 23 CONTROL GP-IGNITION | 1 | |
| 1458462 | 24 PLATE | 1 | |
| 1461800 | 25 HARNESS AS-WIRING | 1 | |
| 4G2544 | CONNECTOR-PLUG | 6 | |
| 1462590 | PLUG AS-CONNECTOR | 1 | |
| 1461815 | 26 STRAP AS | 1 | |
| 9Y6792 | GASKET-SPARK PLUG | 8 |
