System And Components
7C-0447 IGNITION GP-GAS ENGINE (CHG -00 THRU -09)VARIABLE TIMING
Group No: 7C-0447
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E8362 | 1 TUBE AS | 6 | |
| 3P0650 | 2 SEAL-O-RING | 6 | |
| 6I0980 | 3 EXTENSION AS | 6 | |
| 6V3830 | 4 SEAL-O-RING | 6 | |
| 1064128 | 5 SPARK PLUG | 6 | |
| 7E3056 | 6 HARNESS AS-WIRING (IGNITION) | 6 | |
| 0S1618 | 7 BOLT (5/16-18X1-IN) | 18 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 18 | |
| 7W4377 | 8 TRANSFORMER | 6 | |
| 7W5215 | GASKET | 6 | |
| 0S1590 | 9 BOLT (3/8-16X2-IN) | 5 | |
| 0910081 | SPACER (10.5X20X10-MM THK) | 5 | |
| 8T1895 | 10 CLIP (SLOT) | 4 | |
| 8T1896 | CLIP (TAB) | 4 | |
| 7E1429 | 11 HARNESS AS | 1 | |
| 3V3308 | 12 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 7E3222 | 13 MOUNT-FLEXIBLE | 4 | |
| 0S1591 | 14 BOLT (3/8-16X1.5-IN) | 5 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 8T1895 | 16 CLIP (SLOT) | 2 | |
| 8T1896 | CLIP (TAB) | 2 | |
| 9S8750 | 17 NUT-FULL (1/4-20-THD) | 8 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8M9024 | 18 WASHER-HARD (10.2X22.5X5-MM THK) | 3 | |
| 7E8246 | 19 MAGNETO GP | 1 | |
| 7X6034 | 20 STRAP AS-GROUND | 1 | |
| 0S1621 | 21 BOLT (1/2-13X1-IN) | 2 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7E1392 | 22 PLATE | 1 | |
| 4P8466 | 23 BOX AS-CONTROL | 1 | |
| 7W2264 | HARNESS AS | 1 | |
| 2D7134 | 24 STRAP AS | 1 | |
| 6V1196 | 25 SEAL-O-RING | 1 | |
| 1H3338 | 26 LOCKWASHER | 1 |
