100-7931 WIRING GP-SENSOR (CHG -02, -03, -03D1)WITH AIR START

Group No: 100-7931
Part NumberPart NameQty
10092121 HARNESS AS-WIRING1
5P92972 CLIP (LOOP)7
6K49343 CLIP (SLOT)3
6K49354 CLIP (TAB)3
0L20705 BOLT (3/8-16X2.25-IN)6
3V33086 WASHER-HARD (10.2X20.5X2.5-MM THK)43
1B49717 SPACER (0.406X1X1-IN THK)4
5P78548 CLIP (LOOP)5
9Y73919 CLAMP6
0S157110 BOLT (3/8-16X1.75-IN)4
100920911 HARNESS AS-WIRING1
5P236912 CLIP (LOOP)5
103939613 BRACKET AS2
0L135214 BOLT (3/8-16X3.25-IN)10
103939715 CLAMP2
0S158816 BOLT (3/8-16X1.25-IN)13
7E132117 BRACKET AS1
7E132018 BRACKET AS2
100921019 HARNESS AS-WIRING19
112092220 HARNESS AS-WIRING1
5P107521 WASHER-HARD (10.2X22.5X3-MM THK)4
1S099422 CLIP (LOOP)3
0S050923 BOLT (3/8-16X0.75-IN)3
112092124 HARNESS AS-WIRING1
112092025 HARNESS AS-WIRING1
4P758126 CLIP (LADDER)2
104688127 BRACKET AS1
9S875228 NUT-FULL (3/8-16-THD)1
104688229 BRACKET AS1
0S159430 BOLT (3/8-16X1-IN)4
3S209331 STRAP-CABLE8
9X677232 STRAP-CABLE4
4P813433 CLIP (LADDER)2
5P92971 CLIP (LOOP)5
3V33082 WASHER-HARD (10.2X20.5X2.5-MM THK)3
4K10863 U-BOLT2
9S87524 NUT-FULL (3/8-16-THD)8
5P10755 WASHER-HARD (10.2X22.5X3-MM THK)11
6K49346 CLIP (SLOT)2
6K49357 CLIP (TAB)2
0S16218 BOLT (1/2-13X1-IN)2
5P82459 WASHER-HARD (13.5X25.5X3-MM THK)2
0S159410 BOLT (3/8-16X1-IN)3
7K570711 U-BOLT2
7E295312 BRACKET1
7E295413 BRACKET1
4P742914 CLIP (LADDER)1
9X677215 STRAP-CABLE1
110519416 END-WIRE (14-GA)21
110519317 END-WIRE (16-GA)75
109303918 END-WIRE (12-GA)6
