System And Components
196-4930 CONTROL GP-ENGINE MONITORING (CHG -00)PART OF 196-4929 PANEL GP-CONTROL
Group No: 196-4930
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1964931 | 1 BOX GP-CONTROL PANEL | 1 | |
| 3E2155 | 2 FILM-IDENTIFICATION | 1 | |
| 3E2156 | 3 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 3E2158 | 4 FILM-IDENTIFICATION | 1 | |
| 3E2157 | 5 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 9X9616 | 6 COVER-END | 6 | |
| 9X9615 | 7 TERMINAL (SINGLE) | 70 | |
| 9X9675 | 8 BRACKET-END | 17 | |
| 3E0356 | 9 BLOCK-TERMINAL | 2 | |
| 1611145 | 10 BLOCK-FUSE | 5 | |
| 9Y6027 | 11 FUSE-CERAMIC (10-AMPERE) | 10 | |
| 9X9677 | 12 COVER-END | 1 | |
| 9X9676 | 13 TERMINAL | 81 | |
| 9X9612 | 14 COVER (SPACER) | 2 | |
| 9X9674 | 15 TERMINAL | 28 | |
| 1624212 | 16 CONNECTOR-PLUG | 4 | |
| 9X9613 | 17 SPACER (50-MM LGX2.5-MM THK) | 2 | |
| 9X9673 | 18 CONNECTOR (BLOCK) | 2 | |
| 3E0357 | 19 DIODE AS | 2 | |
| 3E2290 | 20 BRIDGE-INSERTION | 1 | |
| 1624210 | 21 STRIP-CONTACT | 9 | |
| 3E0355 | 22 BLOCK-FUSE | 1 | |
| 3E7992 | 23 FUSE (30-AMPERE) | 6 | |
| 1291461 | 24 STRIP-CONTACT | 2 | |
| 3E2246 | 25 MODULE-RELAY (24-VOLT) | 1 | |
| 1593618 | 26 BLOCK-TERMINAL (400-VOLT, 76-AMPERE) | 7 | |
| 3E0310 | 27 DUCT-SOLID | 1 | |
| 3E0311 | 28 COVER | 1 | |
| 3E0308 | 29 DUCT-SLOTTED | 2 | |
| 3E0311 | 30 COVER | 2 | |
| 1762510 | 31 CONTROL GP-ENGINE ELECTRONIC | 1 | |
| 8T4896 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6V8801 | 33 NUT (3/8-16-THD) | 8 | |
| 3E0308 | 34 DUCT-SLOTTED | 1 | |
| 3E0311 | 35 COVER | 1 | |
| 1285605 | 36 DUCT-SLOTTED | 2 | |
| 3E3405 | 37 COVER | 2 | |
| 6V3276 | 38 CONNECTOR AS | 1 | |
| 3E0105 | 39 MOUNT | 4 | |
| 8L8413 | 40 STRAP-CABLE (WHITE) | 1 | |
| 8C6188 | 41 SEAL-SECURITY | 1 | |
| 3E2129 | 42 CONNECTOR AS | 1 | |
| 3E0077 | 43 WINDOW | 1 | |
| 5P5906 | 44 SEAL (11DM) | ||
| 3E0310 | 45 DUCT-SOLID | 3 | |
| 3E0311 | 46 COVER | 3 | |
| 3E0310 | 47 DUCT-SOLID | 1 | |
| 3E0311 | 48 COVER | 2 | |
| 9D3721 | 49 SWITCH-TOGGLE (SINGLE POLE) | 3 | |
| 7D5939 | 50 SEAL | 4 | |
| 3E0308 | 51 DUCT-SLOTTED | 1 | |
| 7E0859 | 52 POTENTIOMETER | 1 | |
| 1J9671 | 53 SEAL-O-RING | 2 | |
| 7E0861 | 54 POTENTIOMETER | 1 | |
| 3E1813 | 55 SWITCH AS-PUSH BUTTON (LIGHTED) | 1 | |
| 3E1814 | LAMP (24-VOLT) | 1 | |
| 3E2148 | 56 SWITCH AS-ROTARY | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 15 | |
| 3E2149 | SWITCH-ROTARY | 1 | |
| 5P5677 | WIRE (18-GA, BLACK)(2DM) | ||
| 7C4910 | SEAL | 1 | |
| 7C4910 | 57 SEAL | 1 | |
| 2W8683 | 58 BLOCK-CONTACT | 1 | |
| 2W8798 | 59 SWITCH AS-PUSH BUTTON | 1 | |
| 4D1836 | 60 SWITCH-TOGGLE | 1 | |
| 1017685 | 61 MODULE-RELAY | 3 | |
| 0870546 | 62 RELAY (24-VOLT) | 2 | |
| 3E3616 | 63 RELAY AS (12-VOLT) | 1 | |
| 5C9553 | 64 BOLT (M6X1X16-MM) | 2 | |
| 8T4205 | 65 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 3E2130 | 66 GASKET | 1 | |
| 3E9335 | 67 CONTROL GP-ENGINE MONITORING | 1 | |
| 8T9834 | 68 PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3132 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 2H8533 | 69 SCREW-MACHINE (10-32X0.25-IN) | 46 | |
| 2W5907 | 70 WASHER (5.16X11.13X0.81-MM THK) | 46 | |
| 6D4712 | 71 DIAL | 2 | |
| 3E8586 | 72 CAP | 1 | |
| 8D9537 | 73 CAP-DUST | 1 | |
| 4P4251 | 74 GASKET | 1 | |
| 6K3274 | 75 PLATE-RIVET | 4 | |
| 6B4540 | 76 NUT (4-40-THD) | 4 | |
| 2S6251 | 77 SCREW (4-40X0.75-IN) | 4 | |
| 1687823 | 78 RELAY-TIME DELAY | 1 | |
| 1977014 | 79 HARNESS AS-ENGINE | 1 |
