System And Components
135-1699 CONTROL GP-FUEL (CHG -06, -07)GAS
Group No: 135-1699
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S3584 | 1 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 3S2713 | 2 NUT-FULL (3/8-24-THD) | 2 | |
| 4D8532 | 3 LEVER | 1 | |
| 4E2250 | 4 HOUSING | 1 | |
| 4P0391 | 5 ROD | 1 | |
| 5H2532 | 6 KEY-WOODRUFF | 2 | |
| 5L3291 | 7 BEARING AS-BALL | 2 | |
| 6D3025 | 8 BALL BEARING | 2 | |
| 6I1732 | 9 VALVE GP-CONTROL | 1 | |
| 7E1630 | 10 GASKET | 1 | |
| 8C5607 | 11 MOUNT-ISOLATION | 6 | |
| 8C5608 | 12 SPACER (6.5X9.5X25.4-MM THK) | 3 | |
| 8C6971 | 13 ROD END | 1 | |
| 8C7315 | 14 ROD END | 1 | |
| 8C7321 | 15 ROD END | 2 | |
| 8H3390 | 16 NUT-FULL (1-1/2-12-THD) | 1 | |
| 9U3300 | 17 SPACER (7X25X50-MM THK) | 3 | |
| 1157768 | 18 LEVER | 1 | |
| 1186663 | 19 BRACKET AS | 1 | |
| 1186665 | 20 SHAFT | 1 | |
| 1271573 | 21 SHAFT | 1 | |
| 1317749 | 22 BRACKET AS | 1 | |
| 1317750 | 23 BRACKET AS | 1 | |
| 1317751 | 24 BRACKET AS | 1 | |
| 1692521 | 25 PLATE | 1 | |
| 1692522 | 26 GASKET | 1 | |
| 1763572 | 27 COUPLING GP-SHAFT | 1 | |
| 1763583 | 28 GUARD | 2 | |
| 1763587 | 29 CLEVIS | 2 | |
| 1937879 | 30 BOOT | 1 | |
| 1969529 | 31 ACTUATOR GP-ELECTRONIC | 1 | |
| 0S1571 | 32 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 33 BOLT (3/8-16X1.25-IN) | 5 | |
| 0S1590 | 34 BOLT (3/8-16X2-IN) | 6 | |
| 0S1591 | 35 BOLT (3/8-16X1.5-IN) | 24 | |
| 2H3429 | 36 RING-RETAINING | 1 | |
| 2L6726 | 37 RING-RETAINING | 1 | |
| 3V3308 | 38 WASHER-HARD (10.2X20.5X2.5-MM THK) | 59 | |
| 8F6302 | 39 BOLT (1/4-20X3.75-IN) | 3 | |
| 8M2337 | 40 WASHER (7.2X24.5X3-MM THK) | 6 | |
| 8M9024 | 41 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9S8752 | 42 NUT-FULL (3/8-16-THD) | 25 |
