System And Components
142-4240 CONTROL GP-FUEL (CHG -03 THRU -06, -06D1)Type 2
Group No: 142-4240
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1S3584 | 1 NUT-FULL (3/8-24 LH-THD) | 2 | |
| 3S2713 | 2 NUT-FULL (3/8-24-THD) | 2 | |
| 4D8532 | 3 LEVER | 1 | |
| 4P0391 | 4 ROD | 1 | |
| 5H2532 | 5 KEY-WOODRUFF | 2 | |
| 5L3291 | 6 BEARING AS-BALL | 2 | |
| 7X7874 | 7 ROD END | 2 | |
| 7X7875 | 8 ROD END | 1 | |
| 8C6971 | 9 ROD END | 1 | |
| 8H3390 | 10 NUT-FULL (1-1/2-12-THD) | 1 | |
| 1157768 | 11 LEVER | 1 | |
| 1186663 | 12 BRACKET AS | 1 | |
| 1186665 | 13 SHAFT | 1 | |
| 1253830 | 14 PLATE | 1 | |
| 1317749 | 15 BRACKET AS | 1 | |
| 1317751 | 16 BRACKET AS | 1 | |
| 1317752 | 17 ADAPTER AS | 1 | |
| 1692522 | 18 GASKET | 1 | |
| 1763583 | 19 GUARD | 2 | |
| 1763587 | 20 CLEVIS | 2 | |
| 1937879 | 21 BOOT | 1 | |
| 2118175 | 22 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 3314483 | 23 BRACKET AS | 1 | |
| 0S1571 | 24 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 25 BOLT (3/8-16X1.25-IN) | 5 | |
| 0S1590 | 26 BOLT (3/8-16X2-IN) | 6 | |
| 0S1591 | 27 BOLT (3/8-16X1.5-IN) | 24 | |
| 3V3308 | 28 WASHER-HARD (10.2X20.5X2.5-MM THK) | 63 | |
| 6V8002 | 29 SEAL-O-RING | 1 | |
| 7Y0725 | 30 WASHER-HARD (52X92X8-MM THK) | 1 | |
| 8M9024 | 31 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 9S8752 | 32 NUT-FULL (3/8-16-THD) | 25 |
